P2.5 Mm High Refresh Rate Led Video Panels With Novastar System MBI Driver IC
P2.5 Mm High Refresh Rate Led Video Panels With Novastar System MBI Driver IC
P2.5 Mm High Refresh Rate Led Video Panels With Novastar System MBI Driver IC
P2.5 Mm High Refresh Rate Led Video Panels With Novastar System MBI Driver IC
Specifications
Brand Name :
EFF
Model Number :
eff/
Certification :
CE/FCC
Place of Origin :
CHINA
MOQ :
1 set
Price :
according to differnt style
Supply Ability :
according to diffeent products
Delivery Time :
15-35 workding days after recieved payment
Packaging Details :
plywood export packing
driving mode :
1/16 scan
meterial :
Alluminum
protection level :
IP32
use place :
indoor
Description





P2.5 Mm High Refresh Rate Led Video Panels With Novastar System MBI Driver IC

Light: Cabinet size 576mmX576mm, Weight 10 kg/pcs;
Thin: Die-cast aluminum design, high precision;
Fast: Fast locks, Easy to assemble and disassemble.
Easy: Modular design, easy assembly and maintenance.
Low: Excellent cooling design, no fans or air-conditioners needed noiseless, low power consumption, cost-effective.
Applications: Indoor enviroments, High definition, High refresh rate, high stability, no noise, light weight and easy to assemble and dismantle.
Specifications:
High definition with an outstanding image and video quality
High refresh rate , with software adjustable, suitable for filming.
High grayscale (16 bits) with perfect visual performance.
High Contras ratio (5000: 1) with black mask and black coating technique.
Wide viewing angle (greater than 140 ° In horizontal).
Lightweight with high strengthen cabinet.
Low power consumption , more energy saving.
Fast and easy to assemble and dismantle.
High reliability and long lifespan (MTBF ≥ 5000 hours).

ModelP3 die-casting aluminum LED board for rental indoor
Pixel pitch3mm
Pixel density111,111 dots /sqm
Module size(W*H)192 mm(width)*192 mm(height)
Module pixels(W*H)64 dots *64 dots
Pixel configuration1Red 1Green 1Blue
Drive modeconstant current driving 1/16 scan
LED lamp typeSMD2121
Cabinet size(W*H*D)576mm*576mm
Color scale65,536 degree
View angle(H/V)140/120 degree
Brightness (White balance)about 1300cd/sqm.
Power consumption(one cabinet)Max:350W / cabinet , Average: 120W / cabinet
Operating VoltageAC110V±10% or 220V ±10%; 47---63HZ
Net weight9Kg / cabinet
Operating temperature-30°C----+60°C
Operating humidity10%-95%RH
Life time≥100,000hours
MTBF5,000 hours
Whole Display Flatness≤0.5mm Juncture
Frame frequency25-60 Hz/s
Refresh rate≥2000Hz /s
Control distance100m (without repeater), single mode fiber:20km, multi mode fiber: 500m
LED control systemLINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable
Operating systemWindows 2000 / Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
Protections for outdoor displayIP31
Maintenance wayRear Access
Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI


P2.5 Mm High Refresh Rate Led Video Panels With Novastar System MBI Driver IC
