P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
P5 Outdoor Rental HD Curved Led Video Wall , 5.95mm Flexible Led Display
Specifications
Brand Name :
EFF
Model Number :
EFF/E
Certification :
CE/FCC
Place of Origin :
China
MOQ :
1 set
Price :
according to quantity
Payment Terms :
T/T, Western Union
Supply Ability :
1000pcs one month
Delivery Time :
7-25days start from got the deposit
Packaging Details :
EPE foam, carton box, wooden case for 46inch Flexible led display screen / led video curtain / rental video wall
Driving Metho :
1/9 scan
Panel size :
500mmx1000mm
Application :
Live events led display
Viewing angle: :
140H,120V
backlit :
LED
Pixels :
5.95mm
Description

p5 Outdoor Rental Led Curve Cheap Led Video Wall 5.95mm Flexible Led Display

Product Description

1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.

Technological Parameters

Items Parameter
Pixel Pitch PH3.9mm PH4.8mm PH5.95mm PH6.944mm
Module Resolution(W*H) 256(W)*128(H) 104(W)*208(H) 96(W)*192(H) 72(W)*144(H)
Pixel Configuration 1R1G1B(in 3 n 1)
LED Encapsulation Black SMD 2121 Black SMD 3528 White SMD 3528 White SMD 3528
Pixel Density 65536 Pixel /m2 43264 Pixel /m2 36864 Pixel /m2 20736 Pixel /m2
Driving Method 1/16 Scan 1/13 Scan 1/16 Scan 1/ 9 Scan
Refresh Frequency ≥1880Hz
Driver IC Special constant current IC with high refresh rate & high grey scale
Grey Scale 14Bit(depending on the system and IC configuration)
Cabinet Size 500*1000mm
White balance Brightness ≥900cd/ m2 ≥900cd/ m2 ≥900cd/ m2 ≥1300cd/ m2
Color Temperature 8000K±500(adjustable)
Viewing Angle Horizontal 140° Vertical 120°
Optimal Viewing Distance >4m >5m >6m >7m
Working Voltage AC 220V/110V±10%
Module voltage DC4.2V
Max Power Consumption 250W/PCS 250W/PCS 330W/PCS 120W/PCS
Avg.Power Consumption 130W/PCS 125W/PCS 170W/PCS 60W/PCS
Lifetime 50000 hours
Operating Temperature –10℃~65℃
Net weight 13Kg/pcs 13Kg/pcs 13Kg/pcs 12Kg/pcs

1. What is LED?

LED stands for Light Emitting Diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor.

2. What are Pixel Pitch and Pixel Configuration?

Pixel Pitch is the distance between neighboring pixels.

Pixel Configuration is the description of the consistence of a pixel.

3. What are LED Type, Module Size and Module Resolution?

LED Type is the description of LED lamp.

Module Size is the measurement of a module.

Module Resolution is the number of pixels per module.

4. What is Drive Method, Driving IC?

Drive Method uses static, 1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former.

Driving IC is the generic term for several kinds of IC, which are used to control the LED lamps.

5. What is Viewing Angle?

Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance.

6. Are you factory?

Yes. We are factory.
