P6 Die Casting Cabinet LED Outdoor Screen for Wedding / Party
P6 Die Casting Cabinet LED Outdoor Screen for Wedding / Party
P6 Die Casting Cabinet LED Outdoor Screen for Wedding / Party
P6 Die Casting Cabinet LED Outdoor Screen for Wedding / Party
Specifications
Brand Name :
EFF
Model Number :
eff/
Certification :
CE/FCC
Place of Origin :
CHINA
MOQ :
1pcs
Price :
according to different style
Payment Terms :
T/T, Western Union
Supply Ability :
1000PCS /MONTH
Delivery Time :
ACCPRDING TO QUANTITY
Packaging Details :
plywood export packing
maintance :
back
using place :
outdoor
cabinet :
Diecasting
purpose :
Renting
Description

P6 Renting Style Die Casting Cabinet LED Outdoor Screen for Wedding

Parameter Value
Physical Parameter Pixel Configuration SMD2020(Balck))
Pixel Pitch( mm) 4.0mm
Pixel matrix per panel 120x120
Pixel density( pixels/sq.m.) 62500
No. of Modules Per Panel (WxH)
(W × H)		 2x2
Cabinet Dimensions (LxWxH)/( mm) 480x480x67
Module Dimensions (LxWxH)/( mm) 240x240
Panel material die casting aluminum
Cabinet weight (kg/panel) 5.1Kg
Module weight (kg/panel) 0.7Kg
Electronic Parameter Color Grayscale (Bit) 14
Gray Scale per Color ( level) 16384
Refresh Rate( Hz) 1920
Driving Type 1/20
Optical Parameter Brightness( nit) 800nits
Optimal Horizontal Viewing Angle( °) 140
Optimal Vertical Viewing Angle( °) 140
Electrical Parameter AC Input Voltage( V) AC220±10%
AC Input Frequency( Hz) 60Hz
AC Input Power Maximum Value( W/m²) 430
C Input Power Typical Value( W/m²) 130
Circumstance Parameter Storage Temperature( ℃) ―10 - 50
Operating Temperature( ℃) 0 - 40
Storage Humidity( RH) 10%~90%
IP rating (Front/Rear) IP40/IP31
Operating Humidity( RH) 10%~90%
Lifetime Typical Value( hrs) 100000
Installation type Cabinet installation type Fix/Front Maintainance

1.Payment Term: T/T 30% as deposit, balanced 70% before delivery.

2.Delivery Time: 10 working days after receiving 30% payment.

3.Packing details: packed by wooden case.

4.Warranty time: 1 years

1)1 years quality guarantee and we will provide free parts for replacement if any problem belongs to us during this period. after the guarantee period, the seller should provide spare parts for replacement based on cost charge.

2)The seller is responsible for permanent maintenance of the panel. During the guarantee period, the maintenance is free of charge (except the defectiveness resulted from man-made damage or force majeure).

3)During the guarantee period the buyer can return the defective components due to technical or quality problems to the seller. The seller is obligated to finish fixing within 5 working days after receiving, and send it back to the buyer without any repairing charge (but the buyer has to pay the delivery cost).

5.Technical Support:

We can send our engineer to guide the installation for you. But the relevant cost should be paid by your esteemed company such as visa, hotel, food, plane ticket for back and forth, and also your esteemed company should pay our staff USD100/day/staff (calculate from our .engineer’s arrival day at customer’s country) and should help to arrange our staff visa
