Address

0~255

Pan range

360°Continue

Tilt range

0°~90° Flip

Manual speed Pan

0.05~240°/Sec

Manual speed Tilt

0.05~180°/Sec

Preset speed

240°/Sec

Preset accuracy

±0.50°

Preset

256

Remote firmware updating and setup

to update firmware by RS485, to set ID by RS485

Cruise Tours

8 Programmable(Dwell time speed preset point)

Speed setup for cruise tour

Yes

Pattern Tours

4 Programmable

Auto Scan

1 Programmable (355° scan )

Alarm

Optional, 4 inputs, 2 outputs

Temperature setup and display

Temperature alarm & display on screen

Time adjustment

to adjust Time by broadcasting

Date/Time setup and display

Date/time display on screen and modify

Timer Programming

timer action

Integrate multi-protocol

Pelco_D/P, PEARMAIN, Pelco C (optional)

Protocol Automatic identify

Pelco_D/P, PEARMAIN

Total working time recording

to record total working time and time exceed limit

Home position

Yes, preset, cruise tour, pattern tour, auto scan, etc. available

Password protection

Yes

Long-focus speed-limited

Yes

Broadcasting address

Yes

Intelligent power-off memory current setting and state

Yes

anti-surge and anti-Lightning protection

Yes

OSD menu operation

Yes

Supporting camera

Automatic identify(Sony, Hitachi, Sanyo, LG, CNB )

Camera menu operation

Yes

Camera character programming

20 character

Privacy masking

Yes

Ingress Protection IP66

Yes

Operating Temperature

–20℃~55℃

Humidity

0%~90% (Non condensing)

Heater operate

(-5)℃ on +5℃ off

Power

24VAC±25%,3A ,60Hz/50Hz

Consumption

heater off 6W heater on 11W

communication

RS485 (+/-) or Manchester

Connection

BNC cable

Image Sensor

1/4" Interline Transfer CCD

Focal Length

12x optical zoom, f=3.94mm(Wide) to 46.05mm (Tele), 16x digital zoom

Zoom Speed

NTSC: 1.9sec, Pal: 1.84sec (Optical WIDE-TELE )

Angular of View

H : Appr. 51.54°(Wide) to 4.49°(Tele) V : Appr. 39.28°(Wide) to 3.39°(Tele)

D : Appr. 62.4°(Wide) to 5.57°(Tele)

Scanning System

2:1 Interlace

Synchronization

Internal/ Line-Lock

Min. Working Distance

1000mm

Aperture Range

F1.67-F1.88

Effective pixels

NTSC: 768(H) x 494(V), PAL:752(H) x 582(V)

Horizontal Resolution

600 TV Lines(Min.) : Color (WIDE) / 680 TV Lines(Min.) : B/W (WIDE)

Signal System

NTSC / PAL

Min. Illumination

0.2 Lux/F1.6 (50 IRE) ; Color / 0.04 Lux/F1.6 (50 IRE) ; B/W

S/N (Y signal)

52 dB

White Balance

ATW/AWC/INDOOR/OUTDOOR/Manual (1700 ˚K to 11,000˚K)

Gain

OFF,LOW,MIDDLE,High,MANUAL Selectable

Backlight compensation

OFF/BLC/HLC Selectable

Video output

CVBS : 1.0Vp-p/75Ω

IRIS Control

Auto,Manual

Electronic shutter speed

NSTC: AUTO (X512 ~ 1/60sec~ 1/120,000

sec ), PAL: AUTO (X512~ 1/50sec~ 1/120,000 sec )

Storage temperature

-20 to 60 °C

Operating temperature

-10 to 50 °C

Power consumption

1.56W : Steady-state (at 12V)

3W : Max. (Zoom,Focus, Day&night motor operating, at 12V)
