Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Black Body Temperature Calibration Device For Thermal Camera Portable Design High Accuracy
Specifications
Brand Name :
pearmain
Model Number :
1791P
Certification :
CE, FCC, ROHS
Place of Origin :
China
MOQ :
1
Price :
negotiation
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
10000units per month
Delivery Time :
7 working days
Packaging Details :
1unit/1 inner box,110*110*180mm/ctn, 1.5kgs
Working Temperature Range :
30℃~50℃
Effective Radiant Surface :
72mm*72mm
Temperature Resolution :
0.01℃
Temperature Measuring Accuracy :
0.1℃
Temperature Stability :
0.15℃/10min
Effective Emissivity :
0.97±0.02
Description

Black Body Temperature Calibration Device For Thermal Camera, Portable Design, High Accuracy@0.01deg.

1791P Black Body Temperature Calibration Device for thermal camera, portable design, High Accuracy @0.01degree

Product Features

The high accuracy black body with wide working temperature range and its effective radiant surface up to 72mm*72mm.

The portable black body is the device for temperature calibrating. And it is mainly used to

calibrate the temperature of radiation thermometer, infrared thermal camera, radiation temperature sensing detector and infrared body surface screening device.

Product Features

*Fast heating speed, good temperature stability, Automatic temperature control.

*Easy to operate, compact design and small in size, easy to carry.

*Simple parameter setting, high precision temperature measurement.

Model Name Black Body
Working Temperature Range 30℃~50℃
Effective Radiation Area 72mm x72mm
Temperature Measuring Accuracy ±0.1℃
Temperature Stability ±0.15℃/10min
Effective Emissivity 0.97±0.02
Dimension 110*110*180mm
Ambient Temperature 0~40℃
Ambient Humidity ≤20%~90%RH
Power Supply AC 24V, 90W

Applications

This black body is a vital role in high-precision body temperature measurement system, usually used with infrared thermometers, It is ideal for the crowd places like airport, railway station, bus station, Subway, coach station, school, residential area, factories, metro transfer hub, and other large-scale venues.
