RS232 Control Monitor Video Wall , Thin Bezel LCD Video Wall Display
RS232 Control Monitor Video Wall , Thin Bezel LCD Video Wall Display
RS232 Control Monitor Video Wall , Thin Bezel LCD Video Wall Display
RS232 Control Monitor Video Wall , Thin Bezel LCD Video Wall Display
Specifications
Brand Name :
DDW
Model Number :
DDW-LW550DUN-THB5
Certification :
ISO9001 , CE , RoHS , FCC
Place of Origin :
Guangdong , China (Mainland)
MOQ :
2pcs
Price :
Negotiable
Payment Terms :
L/C , L/C , T/T
Supply Ability :
3 , 000pcs per month
Delivery Time :
3 working days upon payment
Packaging Details :
First layer carton pack with filling foam , then wood pallet pack
Product Name :
Monitor Video Wall
Bezel :
Thin Bezel
Control method :
RS232 control
Total Physical Bezel :
1.8 mm
Resolution :
1920*1080
Backlit type :
LED
Panel Width :
1211.4mm
Other Name :
LCD Video Wall Display
Description

RS232 Control Monitor Video Wall , Thin Bezel LCD Video Wall Display

Monitor Video Wall Key Features

LED direct-lit backlight with uniform brightness and no boundary shadow.

High display resolution, and delicate image with rich color;

High definition, high brightness, high color gamut

LCD screen with wide angle.

Large display area with light weight

Longer display lifespan

Multiple jointing methods, applicable for various scenes.

Stable running and low maintenance cost, support 24 hours continuous wokring.

Metal case enhances the function of anti-radiation, anti-magnetic filed and strong electric field interference.

Working humidity: 10% ~ 90%, able to work under harsh envionment.

Monitor Video Wall informations:

  • With original LG, Samsung panel, has a stylish design, lighter weight, easy to handle and install;
  • Adapting modular components, making maintenance operations and parts replacement very easily;
  • The installation method: floor standing cabinets;
  • Dot Pitch: 0.63mm(H)*0.63mm(W); Contrast ratio: 4000:1; Responsive time: 6ms;

Monitor Video Wall ​Functions:

  • Supporting 225 units (15×15) multi-matrix;
  • Single screen display. Each unit can display the picture independently;
  • Image overlay. Superimposed on screen another picture;
  • Easy to choose full screen or multi-screen display by control video wall controller.

Monitor Video Wall Specifications

Active Screen Diagonal 55 Inch
Panel Dimension(WxHxD)

1211.4x682.2x53.3mm
Total Bezel Width 1.8 mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backlight System LED
Luminance(nits)

500cd/sqm
Contrast 5000:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor/Outdoor
Working Temperature 0°C~50°C
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing

CCTV Video Wall ​Board Specifications

Support PC Color 24bit
Signal Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ

DVI

HDMI

DP

 Color 24bit
Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ
Interface Input VGA x 1 15pin D-Sub
DVI x 1 DVI-I
DP x 1 Display Port
HDMI x 2 HDMI-19 pin
Output PANEL LVDS 36Pin/2.0
DP out DP loop out
Power Input power DC24V/12V/5V
Drive panel 5V/12V
Power mode Normal working mode, power saving mode
Other OSD Chinese, English and other languages (other languages can be added as required)

RS232 Control Monitor Video Wall , Thin Bezel LCD Video Wall Display
