Specifications
Brand Name :
Chunhuan
Model Number :
100% PTFE Expanded Thread Tape
Certification :
ISO9001
Place of Origin :
China
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
50 Kilograms per Month
Delivery Time :
5--7 working days
Packaging Details :
Wooden box
MOQ :
5 KG
Color :
White
Temperature :
-240 ~ 270℃
Density :
0.8~1
Compressive Strength :
Less than 140Mpa50
Description

White Color Manufacture 17mm 13mm Thread PTFE Waterproof Seal Tape For Plumbers

PTFE Thread Seal Tape also known as sealing tape, stop with the tape. Is a PTFE dispersion resin paste pasting, rolling from the tape without any additives products. White, smooth surface, uniform texture, with excellent heat resistance, corrosion resistance, and self-adhesive, good fit, have a good seal. Can be widely used in pure oxygen, gas, strong oxidants, corrosive media and high temperature steam pipeline thread sealing and pump, valve, equipment, complex shape of the filling seal.

Expanded Thread ISO9001 0.5mm PTFE Plumbers Tape

MAIN PROPERYIES

No Property Result Remarks
1 Heat-Resistance + 370 ℃
2 Cold - Resistance - 190 ℃
3 High Pressure Resistance 150 ~ 200kg/cm2
4 Tensile Strength bigger than 8 Mpa Control according to the demand
5 Percentage elongation bigger than 25 %

TYPES AND SPECIFICATIONS

Width(mm) Thickness(mm) Length(m)

12mm

0.075 4,5,6,7,8,9;7,8,9,10;10,12,13,15,20;20,25
0.1 10,12,13,14,15;18,20;20;8,9,10,12;30,35,40,50,15,20
19mm 0.075 10;15,20;30,35,40;40,50
0.1 8,20;50
0.2 10;15,20;25,30,35
25mm 0.075 10,15,20;30,35,40
0.1 18,20;50
0.2 10;25,30,35

Expanded Thread ISO9001 0.5mm PTFE Plumbers Tape

LICATION

PTFE Thread Seal Tape has a good toughness, vertical strength, easy to deform transverse features.
It is more ideal for sealing plates and threads. However, it can not be used in contact with high concentrations of oxygen or liquid oxygen.
Expanded PTFE tape is mainly used for more disk and thread port seal.

PERFORMANCE

Polytetrafluoroethylene (F4,PTFE) has a series of excellent performance: high temperature resistance-long-term use temperature 200~260 degrees, low temperature resistance-still soft at -100 degrees; Corrosion resistance-resistance to aqua regia and all organic solvents; Climate resistance-extremely long aging life in plastics; High lubrication-has a very small coefficient of friction (0.04) in plastics; Non-sticky-has minimal surface tension in solid materials and does not adhere to any substance; Non-toxic-physiologically inert; Excellent electrical performance, is an ideal class C insulation material. materials are widely used in national defense, military industry, atomic energy, petroleum, radio, electric machinery, chemical industry and other important departments.

APPLICATION

Raw material tape is an auxiliary product commonly used in the installation of liquid pipelines. It is used at the pipe joints to enhance the tightness of the pipe joints. Raw material tape is a novel and ideal sealing material. Due to its non-toxic, tasteless, excellent sealing, insulation and corrosion resistance, it is widely used in water treatment, natural gas, chemical industry, plastics, electronic engineering and other fields.
