Specifications
Brand Name :
Visench
Model Number :
60KVA
Place of Origin :
China
Supply Ability :
10000pcs/month
Delivery Time :
30days
Packaging Details :
Carton
Conversion Time :
0ms
Power Factor :
0.9
Waveform :
Sine Wave
Parallel :
Maximum parallel machine: 3 units
Operating Temperature :
0～40℃
Product Type :
Uninterruptible Power Supply
Size :
533*260*501mm
Overload Capacity :
111–125%: 10 mins, 126–150%: 1 minute
Battery Type :
Sealed Lead Acid
Battery Backup Time :
10-20 minutes
Safety Standard :
IEC/EN 62040-1,IEC/EN 62040-2 IEC 61000
Display :
LCD
Altitude :
≤ 1000m
Environment Humidity :
5 - 95%, no condensation
Output Frequency :
50/ 60Hz
Description

RTX Series

PRODUCT FEATURES

1. 19 inches standard design of rack mount, compact structure .

2. Sin wave output provides best power supply guarantee.

3. 0 conversion time between mains mode and battery mode.

4. It has detection function of input zero line and fire line.

5. Having voltage surge protection function and strong anti-interference function.

6. Equipped with correction function of input power factor

7. Supporting mobile smart monitoring card , users can real-time monitor every data of the UPS by mobile APP.

PARAMETER RTX31 10-20K
Model RTX31 10KS RTX31 15KS RTX31 20KS
Rated Power 　 10kVA/9kW 15kVA/13.5kW 20kVA/18kW
Input Voltage Range 207-475Vac 3P4W+G
Working Frequency Range 40-70Hz (settable)
Input Power Factor ≥0.95
Output Rated Voltage and Accuracy 220Vac(1±1%) 1P2W+G
Output Frequency 46-54Hz synchronize with mains power; 50Hz (Mains power between 40-46Hz and 54-60Hz ); 50Hz(Battery)
Rated Current 45A 68A 91A
Output Power Factor 0.9
Output Harmonic Wave ≤3%
Crest Factor 　 3: 1
Output Overload 105%±5%＜Load≤125%±5%: Convert to bypass output and alarm after 1 min;
125%±5%＜Load≤150%±5%: Convert to bypass output and alarm after 30s;
Load＞150%±5%: Convert to bypass output and alarm after 300ms.
Conversion time between Mains Power and Battery 0ms
Efficiency ＞92%
Battery Rated Voltage 192Vdc
Quantity 16
Charging Current 5.5A
Dimension (LxWxH) mm 665x482.6x132.5 655x482.6x265
Weight 23kg 34kg 35kg
Working Temperature 0℃-40℃
Working Humidity 20%-95%
Noise ≤60dB

UPS 19 Inch Rack Mount UPS 30KVA 40KVA 60KVA for bank,public security and Telecom uninterrupted power supplyUPS 19 Inch Rack Mount UPS 30KVA 40KVA 60KVA for bank,public security and Telecom uninterrupted power supplyUPS 19 Inch Rack Mount UPS 30KVA 40KVA 60KVA for bank,public security and Telecom uninterrupted power supplyUPS 19 Inch Rack Mount UPS 30KVA 40KVA 60KVA for bank,public security and Telecom uninterrupted power supplyUPS 19 Inch Rack Mount UPS 30KVA 40KVA 60KVA for bank,public security and Telecom uninterrupted power supply
