Four HD camera all-round collision warning system with 4G wifi module real-time car monitoring

• Product Description

• Resolution: 1080FHD/720P/VGA
• Cyclic Record: off/1min/2min/3min
• Enhanced Night Vision (HDR): on/off
• Exposure: -3/-2/-1/0/1/2/3
• Motion Detection: on/off
• Recording: on/off
• Date Stamp: on/off
• License Plate: off/on
• Gravity Sensing: off/high/standard/low
• Parking Guard: off/on
• Auto power off: off/3min/5min/10min
• Video selection: before the inside/before the back

• Product Specification

• Standard Features

■ Forward Collision Warning Judging from the relative time to collision (TTC), the system will warn the driver when the host vehicle is too close to the vehicle ahead, allowing him to take measures in time. FCW has 2 levels: level 1 means the vehicle ahead is too close and level 2 means the vehicle ahead is extremely dangerous. Start Speed: vehicle speed > 15km/h);

■ Pedestrian Collision Warning The system will notify the driver of a pedestrian/ cyclist/ motorcycle driver in the danger zone, and alert drivers of an imminent collision with a pedestrian, cyclist or motorcycle driver. Note that PCW also has 2 levels and PCW feature will be closed from 20:00 PM to 06:00 AM. Start Speed: 1km/h < vehicle speed < 30km/h;

■ Lane Departure Warning When the vehicle is veering off the current road lane without turning on cornering lamp, the system will issue an alert to driver. Note that LDW system can detect both full line and dotted line. Also the system can detect if it’s left or right lane departure event. Start Speed: vehicle speed > 50km/h;

■ Abnormal Driver Face State Warning Based on a driver facing infrared camera and advanced technology, the system can understand driver’s basic face states. When it detects an abnormal driver face state event, it will issue an alert to driver. Recognizable facial behaviors as below:

- Driver eye closed (1 second as level 1 and 2 seconds as level 2)

- Driver yawning (0.8 second)

- Driver distracted (4 seconds)

- Driver smoking (0.5 second)

- Driver on the phone (5 seconds after keeping the gesture of calling)

- No driver face detected (20 seconds) Note that the time interval for same type of abnormal driver face state warning is 10 seconds. Start Speed: vehicle speed > 10km/h;

■ Driving Video Recording Record every moment while driving and save the videos inside the SD card. Users can remove the SD card to obtain the videos or use Road eye App to download the videos from TF card to Android smartphone via it’s WiFi hotspot.
