Wide Field Of View Optical Measuring Machine , Optical Measuring Instruments
Wide Field Of View Optical Measuring Machine , Optical Measuring Instruments
Specifications
Brand Name :
Sinowon
Model Number :
iMS-3020P
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Payment Terms :
100% T/T In Advance
Supply Ability :
100 sets per month
Delivery Time :
25 work days
Packaging Details :
plywood
Metal Table :
458x358mm
Glass Table :
356x248mm
Stroke :
300x200mm
Working distance :
200mm
X/Y/Z-axis Travel :
0.0005mm
Video Magnification :
24.5X~156X
Description

Wide Field Of View Optical Measuring Machine , Optical Measuring Instruments

This Optical Measuring Machine iMS-3020P is the best solution for the customer who need both contact measuring and optical measuring requirement.The products are mainly used in industries like automobile, electronics, plastic industrial and precision machinery, etc.

Technical Specification:

Mode

iMS-3020P

Code#

521-160P

Metal Table

458x358mm

Glass Table

356x248mm

X/Y-axis Travel

300x200mm

Z-axis Travel

High-precision linear guide , working travel 200mm

X/Y/Z-axis Travel

0.0005mm

X/Y-axis Accuracy

≤3+L/200(um)

Repeatability

3um

Base and Pillar

High Accuracy Jinan Qing Marble

Illumination System(Software Adjustment)

Surface: Stepless Adjustable 3-ring 8-division LED Cold Illumination

Contour: LED Parallel Illumination

LED Laser Navigation Lights

CCD Camera

High Resolution 700TV Color CCD Camera

Zoom lens

6.5:1 High Resolution Detented Zoom Lens

Magnification:0.7X~4.5X；Video Magnification:24.5X~156X

Standard Delivery:

Product Name

Code#

Product Name

Code#

3D Measuring Software

IM3.1

Video Capture Card

527-130

Contour LED Parallel Illumination

425-100

DELL PC System

581-960

Surface 3R/8D LED Illumination

425-130

AV Video Cable

581-940

Laser Positioning System

581-330

RS232 Data Cable

581-930

6.5X Detented Zoom Lens

421-100

Optical Calibration Block

581-800

HD700TVL Color Camera

484-130

Operation Manual

/
