Automatic Ai Artificial Intelligence Visual Inspection System For Medical PVC Gloves

Visual Inspection System For Medical PVC Gloves

Detection Principle

(1)The inspection equipment, equipped with four sets of high-pixel industrial cameras and lenses, comprehensively detected the defects on both sides of gloves AB. After sample images were collected systematically, the good and defective products were determined by comparison and analysis between image processing software and standardized samples.

(2)When the detection system determines the defective products, the system will give unqualified signals, using the field demoulding device to eliminate, finished products can be detected after the counting function, counting accuracy is 99%.

(3)The software will open the sample comparison standard, the customer site production personnel can control the comparison accuracy, choose the most suitable for their own production situation of the accuracy standard, so as to control the defect rate.

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Equipment Overviwes

​

• Detection range: Automatically detects oil, spots and breakage on gloves
• Features of the product buy a ticket: A high-precision color camera is used to detect pixel-level dirt and oil stains on gloves. The testing system independently developed by the company can achieve different testing functions according to different products and requirements
• Blackheads and black spots: The area threshold is adjustable between 0.2 and 0.5 mm²
• Breakage and oil pollution: the area is over 0.5mm ²
• The detection accuracy is greater than 99.5% and the error elimination rate is less than 2%

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Our Advantages

1. AI algorithm: high stability, adapting to the environment and background disturbance; different defect samples can be automatically identified after training.
2. Dataization: Independent database, save multiple samples, analyze non-good products, and retain history.
3. Multi-orientation: 360 degree comprehensive inside and outside the bottle without dead corners for medical packaging bottle caps, bottle mouths, bottle bottoms.
4. High precision: detection accuracy can reach 99.5%.
5. Modularization, can flexibly increase or decrease the detection function according to customer actual needs.
6. Easy to operate: It is easy to operate and easy to maintain.
7. Safety: Medical grade material manufacturing, fully compliant with medical supplies production environment.

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------

------------------------------------------------------------------------------------------------------------------------------------------------------------------------
