CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck
CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck
CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck
CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck
Specifications
Brand Name :
VMAX
Model Number :
CPCD30
Certification :
CE,BV,SGS,ISO9001
Place of Origin :
CN
MOQ :
1 unit
Price :
＄7,200.00-＄7,400.00/unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5,000 units/year
Delivery Time :
25-30 days
Packaging Details :
nude package
Power souce :
diesel engine
Load center :
500mm
Fork length :
1070mm
Overall dimensions :
2682mm*1225mm*2090mm
Type :
Diesel Forklift Truck
Fork width :
125mm
Transmission :
automatic
Free lift height :
160mm
Max. lifting height :
3000mm
Engine :
China engine Xinchai 495BPG, Euro II,Japanese ISUZU C240 Mitsubishi S4S Yanmar 4TNE98
Loading capacity :
3000kgs
After-sales Service :
Overseas Third-party Support Available, Engineers Available To Service Machinery Overseas, Online Support, Overseas Service Center Available, Free Spare Parts.
Warranty :
1 year or 2000 hours
Description

VMAX Automated 3ton forklift counterbalance forklift truck CPCD30 FD30 diesel powered forklift

Advantage:

As one of the most famous material handling manufactures in China,we specialize in this field for over 10 years, with the strength of diesel forklift , Electric forklift , LPG forklift , reach truck, pullet truck and stacker.

Now VMAX dealers has been wide spread in many countries like Russia, Australia,Turkey, Brazil, Mexico etc. Also We company had obtained the following certificates in this industry with the development of over 10 years:
1. CE certificate
2. ISO 9001:2008 Standard approved
3. BV&SGS Factory Audit Pass Report
4. Alibaba golden supplier for 7 years

Besides, we are always trying to be innovative and have won several patent certificate on forklift in China.
Currently the factory's capacity per year is 5000 sets(including all sorts of forklift) and averagely the leading production time is 20-30 days. While standing to expand our brand, we also gladly accept OEM based model in which you can pick Japan Engine/Curtis Controller/different forklift attachment and any you like.

VMAX do more than just selling product, but also provide material handling solution for customer. We're sure that it can satisfy your demand if needed.

3 ton diesel forklift Standard Installment:

--Model CPCD30,load capacity 3000kg.

--Automatic transmission, 3M 2stage Mast.

--China engine Xinchai 495BPG, Euro II.

--1070mm fork,Pneumatic tyes.

--Safety seat with steady belt,warning light.

--Free tool box,spare parts.

Product Characteristics:

  • Integrated central control box the reliability of electric system
  • Ergonomical design ensures best operation
  • Energy-saving hydraulic system decreases fuel consumption
  • High-quality hydraulic hoses, no oil leakage
  • Wide-view mast design improves the productivity and safety

automatic lift truck OPTION:

As a professional manufacturer of forklift, we also can offer you customized service,

the following items are optional:

Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m

side shifter, fork positioner,longer forks, fork extension

For the details of customized configurations and options, please contact with us.

VMAX professional service will be impressed on you.

OTHERS :
A:date of delivery:15-25days after received the deposit
B:payment terms:T/T(30% deposit,balance paid before shipment).Or L/C at sight
C:Guaranty period: one year or 2000hours upon receiving goods.

automatic lift truck specification:

3T COUNTER BALANCE DIESEL FORKLIFT TRUCK SPECIFICATION
Model Unit CPC30/CPCD30
Power type Diesel
Rated capacity kg 3000
Load center mm 500
Mast Lifting height mm 3000
Free lift height mm 175
Fork size(L*W*T) mm 1070×125×45
Tilting Angles(Front/Rear) deg 6°/12°
Front overhang mm 485


Exterior Size		 Length without fork mm 2680
Overall width mm 1225
Mast drop mm 2065
Max.lift mm 4250
Front-wheel Overhead mm 2070
Min Turning Radius mm 2420
Min.intersecting aisle mm 2100


Speeds		 Max Driving speeds km/h 18.5/20
Lifting speeds mm/s 470/520
Lowering speeds mm/s 550/520
Max.grade ability % 20
Total weight kg 4300

Tires		 Front 28*9-15-12PR
Rear 6.5-10-10PR
Wheelbase mm 1700

Tread		 Front mm 1000
Rear mm 970
Min.ground clearance mm 110


Engine		 Model XINCHANG490BPG
Rated output kw/rpm 37/2650
Rated torque N.m/rpm 148/1800
No.of cylinder 4
Displacement L 2.54
Fuel tank capacity L 52


CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck

CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck

CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck

CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck

CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck

CPCD30 FD30 Diesel Powered Forklift Automated 3 Ton Counterbalance Forklift Truck
