IP65 Outdoor LED Gas Board Signage Display for Gas Station Changing 5000cd/sqm

Specifications

Application :

Outdoor, Gas Station

Type :

LED

Color :

Gas Station, Red

Panel Size :

6-72inch, 6-72inch

Supplier Type :

Original manufacturer

Media Available :

datasheet, Photo

Place of Origin :

Guangdong, China

Model Number :

GL-8.889 /10

Brand Name :

Glare-LED

use :

advertising publish, Gas Station

Pixel Pitch :

Other, Other

Specification :

No specification

HS Code :

8531200000

Resolution :

150w

Usage :

OUTDOOR

Tube Chip Color :

Red

Pixels :

10mm

Screen Dimension :

8-32inch

LED chip :

Epistar led trffic chip

Brightness :

5000cd/sqm

waterproof level :

IP65

working temperature :

-20-60°

viewing angle :

120 Degrees

Price :

Negotiable

Description

waterproof IP65 24 inch 8.889 Led Gas Price Signen

Product Description

Gas station 7 segment digital LEDtechnical specifications

Item	Technical Specifications
Color	Red, amber, green, blue or white optional.
Digital Height	6'', 8'', 10'', 12'', 16'', 18'', 20'', 24'', 27'', 32'', 36'', 40'', 48'', 60'', 73'' etc.
Digital Design	6'', 8'', 10'', 12'', 16'', 18'', 20'', 24'', 27'', 32'': standard digit.
Brightness Control	Auto-dimming by sensor or remote control.
Display Dimming	Over 8 levels of automatic intensity adjustment.
Viewing Angle	120(H)/40(V)
Maintenance	front side or back side
Master/ Slave	Single/ Double/ Three/ Four sides, use one control card, all working. Or customized.
Casing Material	Steel, Aluminum available.
Front Cover	Displays with 32'' & over digit high are without front cover; Others with front cover.
Waterproof Level	IP 54 from 4'' to 32'' Outdoor, IP 65 front & IP 54 rear from 32'' to 72'' Outdoor.
Temperature Sensor	Default economical sensor, All sensor is available for more exact request.
LED Driving mode	Constant Current
Power Input	110/220VAC, 60Hz/50Hz
PC Communication	Available in RF/LCD/RS232/TCP/IP
Communication	8m
Remote control type	300ft/ 100m, range of RF remote control.
Continuous Working Time	Unlimited
Lifetime of LEDs	>100,000hours
Installation Method	Hanging, mounting or per custom design
Working Temperature	Indoor: -11 ℃~40 ℃, Outdoor: -20 ℃~60 ℃, Humidity:15%~95%RH
Display Format	8.88,8.888, 8.889, 8.88 9/10 etc
Name	pcb board petrol gas station led numeric display

Project pictures of Gas station 7 segment digital LED
