Specifications
Place of Origin :
Guangdong, China
Model Number :
GLG-P16
Brand Name :
Glare-LED
MOQ :
120 pieces
Price :
Negotiable
Application :
Highway Traffic Message LED Display
Type :
LED
Color :
2A 2R1G 1R1G1B
Panel Size :
256*128mm, 256*128mm
use :
advertising publish, outdoor
Pixel Pitch :
Other, Other
Specification :
8*16
Touch Screen Type :
none
Brightness :
12000cd/㎡, 12000cd/㎡, 12000cd/m2
HS Code :
8531909000
Resolution :
16*8
View Angle（H/V） :
30°, 30°
Usage :
Highway Traffic Message LED Display
Display Function :
Video, photo, text
Product name :
P16 LED Module
Warranty :
2 Years
LED chip :
Epistar chip
Module size :
256*128mm
Max Power consumption :
310
Drive Method :
Static
wateproof level :
IP65
Description

Large Led Billboard Full Color Rgb Dip P16 Led Modules For Outdoor Advertising Display

Large Led Billboard Full Color Rgb Dip P16 Led Modules For Outdoor Advertising Display
Large Led Billboard Full Color Rgb Dip P16 Led Modules For Outdoor Advertising Display
Large Led Billboard Full Color Rgb Dip P16 Led Modules For Outdoor Advertising Display
Large Led Billboard Full Color Rgb Dip P16 Led Modules For Outdoor Advertising Display

PRODUCT OVERVIEW

P16 Outdoor full color DIP LED modules are with IP65 waterproof level, high emitting efficiency, long lifespan. Which has good display effects, bright color, high brightness, far viewing distance, very suitable for outdoor traffic variable message signs and outdoor advertising displays usage.

PRODUCT FEATURES

High brightness: use high brightness LED lamps High uniformity: LED display with super high color uniformity, display images are more smooth Good flatness: the surface flatness of module mounting are within ±0.2mm Good effect: using non-linear correction, the image clearer, and have an extra layer ; Wide waterproof aprons: using wide waterproof aprons, making contact area more wide from the frame cabinet to module ,good seal, good waterproof effect. Reliability: using a variety of scanning technology and Modular design techniques, higher reliability and stability stability board : board’ circuit using wave soldering machine, with green oil oxygen barrier, preventing the line of wet and oxidation to improve working life; With three anti-paint: protect the board’ circuit and related equipment from the erosion of a bad environment; have a good resistance to high temperature; after cured into a transparent protective film, has a superior effect of defect the board form electroconductive, moisture, leakage power, shock-proof dust, corrosion, aging and corona ,etc. Waterproof glue: automatic glue-pouring machine, to ensure uniform, smooth, and waterproof; Strict testing: Products through a series of stringent testing and measures, such as raw material testing, production process testing, product aging testing etc.
PROUCT SPEC
Product name
P16
screen weight(kg/m²)
70
LED Package
Φ5
Input voltage (DC)
5V
Horizontal viewing angle
≥30°
Maximum current
1.2/1.5/2A
Vertical viewing angle
≥15°
Maximum power (W/m2)
6/7.5/10W
Brightness
≥12000 CD/㎡
MTBF
≥10000 hours
Pixel pitch
16 mm
Life time
≥50000 hours
Pixel density
900 Dots/㎡
Pixel out of control rate
﹤1/10000
Pixel composition
4R/4R2G/4R2G1B/custom
max contrast
1000:1
Led Module resolution
8*4 Dots
refresh rate (Hz)
>960
Driving mode
static ；constant current
Working environment
Outdoor
Minimum viewing distance
34m
Working temperature
-20 to 60℃
Led Module size (W*H)
256*128*33(mm)
Working humidity
10% to 90% RH
Led Module weight
550±10g
Interface definition(HUB12)
2 A B C S L R G D 16
1 O N N N N N N N 15
Flatness
≤0.2 mm
