ZM6134 Computerized Compressed Air Thermodynamic Cycle Trainer Refrigeration Training Equipment

I. Product overview

This trainer is designed to study character of a 2-step air compressor, observe and study character of compressed air, when running, it needs to be connected with ZM6135 compressed-air dehumidification trainer at the same time to make sure air in storage tank is available compressed air which is dry and clean. This training equipment simplify data acquisition process, using proper sensor and processor to show experiment data on computer and achieve control of computer on trainer.

II. Product feature

The training bench takes aluminum frame structure, it is concise and fastness, it is not only to lighten the equipment, but also ensure the strength of equipment, it is equipped with 4 universal casters on its bottom, which is easy to move.

The air compressor and motor are integrated on bench, structure is compact, one outlet of 2-step compressed air can measure temperature, pressure and humidity at the same time, which is convenient for student to observe and record.

The equipment is fitted with good safety protection system. Outlet of 2-step compressed air is equipped with high-low pressure protection switch in refrigerating cycle, when system pressure is abnormal, the compressor can stop work immediately to protect compressor and system. It is equipped with earth leakage circuit breaker, emergency stop and reliable ground protection in electrical circuit, which is to ensure safety of equipment and personal.

III. Technical data

(1) Input power supply: 380V±10%, 50Hz

(2) Overall dimension: 1400mm×800mm×1800mm

(3) Weight: 410kg

(4) Operatingdition: environment temperature 10℃~30℃,RH ＜75% (25℃)
