ZE3121 Induction Machines Trainer Experiment Equipment Vocational Training Equipment

1 Overview
1.1 Introduction
This training set include various of induction motors, students can be
familiar with various types of induction motors features, control
principles, and knowledge through training and experiments. It is
suitable for students in vocational schools, technical schools, colleges.
1.2 Feature
(1)Training workbench use aluminum column structure frame, there is
universal wheels at the bottom of trainer, you can move it as you like.
It include meter box and power box to test and measure technical parameter,
it is easy to use and it is not easy to be broken.
(2) Equipped with transformers, students can make combination, and
finish many training contents and experiments.
(3) Training workbench has high safety system.
2 Technical parameter
(1) Input power: three phases, five wires, 380V±10% 50Hz
(2) Dimension: 1200mm×800mm×1500mm
(3) Whole capacity:＜1.5KVA
(4) Weight: ＜300kg
(5) Work environment:
Environment temperature: -10℃～+40℃
Relative humidity: ＜85%(25℃)
3 Product consist of
3.1 Power control panel
Power control panel use aluminum structure metal panel, all close type
Boxes structure
3.2 Training workbench
Training workbench use anti fire board surface, it is very sound and
not easy to be broken, it has a beautiful outlook.
3.3 Power control panel
(1)Single phase, three wire power input, it has been tested by leakage
breaker control, it has emergency stop button, you can cut off electricity
when emergency.
(2)Control panel has one point type voltage meter, one current meter,
one power meter, one non power meter.
(3)It equipped with indicator, Europe power plug output, safety output
sockets.
(4)Inner AC current and DC wound power, with short circuit protection function.
4 Training content
4.1 Single phase capacitive motor experiments
(1) Single-phase capacitor motor static test
(2) The principle of single-phase capacitor motor characteristics and run test
(3) Single-phase capacitor motor start and stop control
(4) Single-phase capacitor motor centrifugal switch control
4.2 Three phase asynchronous motor experiments
(1) Three phase asynchronous motor principle and features
(2) Three phase asynchronous motor static test
(3) Three phase asynchronous motor function test
(4) Three phase asynchronous motor forward and reverse control
(5) Three phase asynchronous motor star and delta control
(6) Three phase asynchronous motor contactor control
4.3 Three phase winding motor experiments
(1) Three phase wind asynchronous motor principle and features
(2) Three phase wind asynchronous motor static test
(3) Three phase wind asynchronous motor connect and function
(4) Three phase wind asynchronous motor function technical parameter setting
(5) Three phase wind asynchronous motor start and stop control
4.4 Three phase wind synchronous motor experiments
(1) Three phase wind synchronous motor principle and features
(2) Three phase wind synchronous motor static test
(3) Three phase wind synchronous motor connect and function
(4) Three phase wind synchronous motor function technical parameter setting
(5) Three phase wind synchronous motor start and stop control
4.5 Three phases double speed motor experiments
(1) Three phases double speed motor principles and features
(2) Three phases double speed motor static test
(3) Three phases double speed motor connect and function
(4) Three phases double speed motor technical parameter function and test
(5) Three phases double speed motor start and stop control
(6)Three phases double speed motor high speed and low speed function
(7) Three phases double speed motor speed change control
4.6 Electrical machines comprehensive experiments
(1)Electrical machines load features test
(2)Electrical machines function technical parameter test
(3)Electrical machines electric technical parameter test
Supply English user manual

Arrange delivery within 45 days upon receipt of payment.

Please see below photo for detailed package.
