SR2101S DC Motor Training Equipment

1 Product Overview

1.1 Overview

The training device includes various types of motors and industrial control components. Through relevant experiments, you can familiarize yourself with the operating characteristics of DC motors and the use of various industrial control components, master the control principles and control methods, and cultivate students' corresponding knowledge and Skills, suitable for higher vocational, higher vocational, secondary vocational schools and technical and vocational schools related teaching and skills training assessment.

1.2 Features

(1) The training platform adopts aluminum profile column frame structure, the whole is simple and generous, and the universal wheel is installed at the bottom. It can be moved flexibly and can be adjusted independently according to the ground conditions. It is convenient to use and not easy to damage.

(2) A variety of types of motors, fully equipped, can be used in combination.

(3) Combination of software and hardware, can complete the training content of a variety of courses

(4) The training platform has a good security protection system.

2 performance parameters

(1) Input power: three-phase five-wire system 380V±10% 60Hz

(2) Dimensions: 1600mm × 800mm × 1800mm

(3) Machine capacity: <2KVA

(4) Weight: <200kg

(5) Working conditions: ambient temperature -10 ° C ~ +40 ° C Relative humidity <85% (25 ° C)

3 product composition

3.1 Training table

The training table is supported by aluminum profiles and the universal wheel is attached to the bottom. It can be moved flexibly and can be adjusted independently according to the ground conditions. The desktop is made of 25mm thick high-density substrate, and the surface is treated with high-temperature and high-pressure fireproof board. The structure is firm and the whole is simple and generous.

3.2 Power Box Introduction

4 can complete the training content

4.1 compound excitation DC motor experiment

(1) Motion function and transmission group test

(2) Static test of motor technical parameters

(3) Motor control circuit connection and function

(4) Technical test of sports function

4.2 Motor torque, speed, power measurement experiment

(1) Hardware connection and display

(2) Software connection and display

4.3 Three-phase squirrel cage asynchronous motor experiment

(1) Familiar with the characteristics of three-phase squirrel cage asynchronous motor.

(2) Master the star start and triangle start method of three-phase asynchronous motor.

Product Details and Warranty
We supply suitable spare pats according to experiment requirement, our products take aluminum structure, A4 paper dimension aluminum and plastic hanging box structure.
We supply 3 years warranty time.

Packaging & Delivery
Package details: plastic film+ plastic foam + plywood box with pallet, and for equipment dimension less than 1CBM, we supply plastic film+ plastic foam+ fine carton.

Arrange delivery within 45 days upon receipt of payment.
