Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Plas
Supply Ability :
10000 Square Meters
Packaging Details :
Carton
MOQ :
50 square meter
Price :
$2-8.36 square meter
Payment Terms :
T/T, Western Union
Delivery Time :
10-15 days
Material :
Polyimide
Use :
Masking
Adhesive Side :
Single Sided
Adhesive :
Acrylic, Silicone adhesive
Adhesive Type :
Pressure Sensitive
Feature :
Heat-Resistant, specially treated with imported agent
Design Printing :
No Printing
Thickness :
0.05/ 0.06mm
Packing :
Roll Packing
Transparency :
Transparent
length :
33m/66m
Width :
500 mm,OEM
Application :
metal,glass,plastic, LCD nameplates,screens ,computers, PAD
Color :
Amber
Port :
Shenzhen,China
Description
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
Feature:

The heat resistant tape is used polyimide film as a substrate, specially treated with imported agent. It will leave no residue when removed. High temperature resistance, abrasion resistance, good mechanical properties. Widely used in the electronics industry.

Structure:

Substrate

Polyimide film(PI)
adhesive

Silicone adhesive

Release film

Fluoro-Silicone release film

Application:

Widely used in the electronics industry.

Products detail:

Color

Amber

Thickness

0.05mm(XHT-PI5050), 0.06mm(XHT-PI6050)

Length

33M, 66M

Width of the master roll

500mm

Elongation

50%

Tensile strength

≥42N/25mm

release force

≥26N/25mm

Initial adhesion

24#
Permanent adhesion

48H

Temperature tolerance(short term) ≤280℃
Temperature tolerance (long term)

≤260℃

Note: The technical information and data, recommendations and other statements provided are based on tests and experience that we think are reliable, but the accuracy or completeness of such information is not guaranteed. We suggest you to evaluate this product and determine whether it is suitable to your application before using it.

Storage: The tapes should not be exposed to direct sunlight, heat or freezing. Stored in a cool and dry place under temperature of 4-26℃ with RH 40-50%.

Shelf life: 6 months for the day of manufacture.

Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape

Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape

Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape

Company Information

Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating TapeHeat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape

Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape

Packaging & Shipping
Heat Resistant Polyimide Film Tape for 3D Printing Soldering Insulating Circuit Boards Insulating Tape
FAQ

Q: The Terms of Payment?

-- T/T;Western Union;L/C ; Trade Assurance; etc. Depended On Different Country And Different Quantity.

Q: Delivery date?

-- Normal 0-7days, Depended on different quantity.

Q: Transportation method?

-- By international Express,DHL,UPS,Fedex,TNT etc.

-- By sea

-- Dipended on different quantity and different country;

Q: Why choose Us?

-- We have professional Research and development Team

-- More than 12 years in this fild;

-- OEM is welcome
