Servo System PLC Relay Module 5A 250VAC 2 CO Output Output Contacts
Servo System PLC Relay Module 5A 250VAC 2 CO Output Output Contacts
Servo System PLC Relay Module 5A 250VAC 2 CO Output Output Contacts
Servo System PLC Relay Module 5A 250VAC 2 CO Output Output Contacts
Specifications
Brand Name :
GINRI
Model Number :
JR-12L2
Certification :
CE,CCC
Place of Origin :
CHINA
MOQ :
10Pcs
Payment Terms :
L/C, T/T, Western Union,Paypal
Supply Ability :
20000Pcs per month
Delivery Time :
1-30 days upon order quantity
Packaging Details :
Voltage relay is standard seaworthy package,1pcs individual box or 5pcs in a middle box, 200pcs per carton. Base quotation is blank package. OEM design is acceptable
Input Signal :
NPN & PNP compatible
Input Voltage :
DC5V 12V 24V, AC110V 220V
Output Voltage :
AC/DC 0-250V
I/O points :
12 CHANNEL
Mounting :
Din Rail
Output Contacts :
2CO(DPDT)
Description

Servo System PLC Amplified Board 5A 250VAC 2 CO Output Output Contacts

Product advantage

1. Module integration, with work lights, beautiful and clean time, space-saving costs

2 . Output input with common terminal, bidirectional indicator input compatible, trouble-shooting easy to save trouble,easy to wiring and mount

3 . Powerful manufacturer ,quanlity assurance

4 . The circuit is designed to work independently for each channel, freewheeling secondary can be added, the output can require a total of com, high power load output can be thickened with tin plating to ensure load capacity

5 . Plug-in mount design , repair and replacement more easier

♦ Features

-- Standard DIN rain mounted

-- Status indication for each input

-- Special circuit for self anti-interference

-- Isolation for each relay channel

-- with relay base, easy to replace

♦ Typical Applications

• Micro-controller • PLC control • Servo System

• Electro-magnetic valve • DC Motors

• Home intelligent control

♦ Approvals

• CE • CCC

♦ Technical date

Model JR-12L2/24VDC
Output type OMRON Relay
I/O points 12
Input signal NPN and PNP compatible
Input voltage

DC24V

* DC5V,DC12V,AC110V,AC220V can be customized.
Output voltage AC/DC 0-250V
Output Contacts 2CO(DPDT)
Contact capacity(resistive) 5A 250VAC
Operation voltage/Release voltage ≥75%Un/≤10%Un
Operation time/Release time ≤15ms/≤8ms
Switching frequency 0.1Hz
Dimensions(WxH) 87×63mm
Mounting DIN rail

Servo System PLC Relay Module 5A 250VAC 2 CO Output Output Contacts
