12 Channel Slim PLC Relay Module Interface OMRON Relay 220VAC PLC DC Amplified Board
12 Channel Slim PLC Relay Module Interface OMRON Relay 220VAC PLC DC Amplified Board
12 Channel Slim PLC Relay Module Interface OMRON Relay 220VAC PLC DC Amplified Board
12 Channel Slim PLC Relay Module Interface OMRON Relay 220VAC PLC DC Amplified Board
Specifications
Brand Name :
Ginri
Model Number :
JR-2L1
Certification :
CE
Place of Origin :
Wenzhou
MOQ :
10
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
1000 per month
Delivery Time :
5-7 work day
Packaging Details :
6*10*7
Output type :
Omron relay*other brand cam be customized
I/O points :
1.2.4.6.8.12.16
Input signal :
NPN and PNP
Input voltage :
AC/DC 0-250VAC
Output contacts :
1CO(SPDT)/2CO(DPDT)
Output voltage :
AC/DC 0-250V
Description

1 2 Channel Slim PLC Interface OMRON Relay , 220VAC PLC DC Amplified Board

PLC amplification board also known as PLC isolation amplifier board, PLC current conversion board, PLC load driver board, PLC output amplifier board, PLC voltage conversion board, the main role is to isolate the PLC output and the load, the load is short-circuit not directly burned The advantages of the programming controller (PLC) and the PLC amplifier board compared with the conventional intermediate relay are that the PLC amplifier board has a surge absorption circuit, the load generates a surge voltage current when it is disconnected, and the induced electromotive force is effectively absorbed. Extended use life.

PLC amplification board is divided into three series, a PLC relay amplifier board, two PLC transistor amplifier board, three PLC thyristor amplifier board, there are a lot of dedicated PLC amplifier board.

The biggest advantage of PLC amplifier board is convenient wiring, especially FX2NC, FX3UC, Panasonic FP dedicated PLC amplifier board, input directly with IDC plug input, not one by one wiring, output wiring is also convenient, European terminal, as long as a small A flat-blade screwdriver is enough. There are two kinds of general-purpose PLC amplifying boards that are European-style terminal wiring. With a flat-blade screwdriver, there is a common and independent type of the male point. If the common point-type wiring is also convenient, it is better than the intermediate relay. A lot of short wiring, PLC internal shorting board, there is a Japanese terminal, is a 10 word screwdriver wiring common and independent type, if your common point type wiring is very convenient, this can Directly using 2.5-3, 2.5-4 cold crimp terminals, the number of lines on the sleeve is also very convenient. Afterwards, it is a trend to use the PLC amplification board for the electric cabinet. The space occupied by the cabinet is small, and it is still relatively high-grade.

Feature:

  • Standard DIN rail mounted

  • Status indication for each input

  • Special circuit for self anti-interference

  • Isolation for each relay channel

  • With relay base,easy to replace

Application:

  • Micro-controller

  • PLC control

  • Servo Systems

  • Electro-magnetic valve

  • DC motors

  • CNC machine

  • Home intelligent control

Model JR-XL
Output type OMRON relay*other brand relay can be cutsomized
I/O points 1,2,4,6,8,12,16
Input signal NPN and PNP compatible
Input voltage DC24V*DC5V,DC12V,AC110V can be customized
Output voltage AC/DC 0-250V
Output contacts 1CO(SPDT)/2CO(DPDT)
Contact capacity(resistance)

1CO:19A 250VAC

2CO:5A 250VAC
Operation voltage/Release voltage ≥75%Un/≤10%Un
Operation time/Release time ≤15ms/8ms
Switching frequency 0.1HZ
Electrical durability 100000 cycles
Mechanical durability 10000000 cycles
Applicable wires AWG 26~12(0.2-2.5mm²),6-7mm
Dimension(WxH) 87X63mm
Mounting Din rail
