Phase Failure / Phase Sequence / Phase Asymmetry Relay , Din Rail Mount
Phase Failure / Phase Sequence / Phase Asymmetry Relay , Din Rail Mount
Phase Failure / Phase Sequence / Phase Asymmetry Relay , Din Rail Mount
Phase Failure / Phase Sequence / Phase Asymmetry Relay , Din Rail Mount
Specifications
Brand Name :
GINRI
Model Number :
JVR-381
Certification :
CE
Place of Origin :
China
MOQ :
10Pcs
Payment Terms :
L/C, T/T, Western Union,paypal
Supply Ability :
20000Pcs
Delivery Time :
5-8 working days
Packaging Details :
1 relay in individual box and 10pcs in middle box
Voltage :
380V
Monitor :
Phase Asymmetry
Mount :
DIN Rail
Output Contact :
1 C/O
Description

Three Phase Voltage Relay Phase Failure/Phase Sequence/Phase Asymmetry Relay JVR-381

♦ Features

-- Three-phase monitoring of phase sequence, phase loss and phase unbalance

-- Powered by the measuring circuit

-- 1 C/O contact

-- 3 LEDs for status indication

♦ Protective Functions

-- Phase sequence

-- Phase loss

-- Phase unbalance

♦ Typical Applications

• Pumps • Fans

• Blowers • Motors

• Compressors

♦ Approvals

• CE • CCC

♦ Technical data

Type JVR-381
Measuring circuit L1,L2,L3
Rated voltage

220VAC,380VAC ,440VAC

460VAV,480VAC,50/60Hz
Monitoring functions phase sequence, phase loss, phase unbalance
Indicators phase sequence, phase loss and normal
Output contacts 1 C/O
Contact capacity 3A ,250VAC
Dimensions (H x W x D) 68×30×76mm
Mounting DIN rail

Phase Failure / Phase Sequence / Phase Asymmetry Relay , Din Rail Mount

Product tags

din rail solid state relay

,

din mount relay

,

din rail relay
