24V Single Phase Relay Overvoltage Under Voltage Protection CE Passed
24V Single Phase Relay Overvoltage Under Voltage Protection CE Passed
24V Single Phase Relay Overvoltage Under Voltage Protection CE Passed
24V Single Phase Relay Overvoltage Under Voltage Protection CE Passed
Specifications
Brand Name :
GINRI
Model Number :
SVR1000
Certification :
CE
Place of Origin :
China
MOQ :
10Pcs
Payment Terms :
L/C, T/T, Western Union,Paypal
Supply Ability :
20000Pcs per Month
Delivery Time :
5-8 working days
Packaging Details :
1 relay in individual box
overvoltage :
20-80V
rated voltage :
AC/DC24-48
monitoring functions :
under voltage
delay time :
0.1-999a
Description

GINRI Over Under Voltage Relay 24V overvoltage under voltage protection relay

The Features of SVR10000

-- Powered by the measuring circuit

-- Built-in LCD and keypad afford a precise,digital setting

-- Compact modular 43mm housing

-- Adjustable over- and undervoltage threshold

-- Independent adjustable delay time for overvoltage, undervoltage

-- 1 CO & 1NC contacts

-- Fault recording with last 3 faults

♦ Protective Functions

-- Overvoltage

-- Undervoltage

♦ Typical Applications

• Pumps • Fans

• Blowers • Motors

• Compressors

♦ Approvals

• CE • CCC

♦ Technical data

Model SVR1000/D12 SVR1000/AD48 SVR1000/AD220
Measuring circuit A1+,A2-
Rated voltage DC 12V AC/DC 24~48V,50/60Hz

AC/DC

110~240V,50/60Hz
Monitoring functions overvolatege, undervoltage
Overvoltage setting range

DC

9.0~18.0V adjustable

 AC/DC 20.0~80.0V adjustable

AC/DC

50.0~300V adjustable
Undervoltage setting range

DC

9.0~18.0V adjustable

 AC/DC 20.0~80.0V adjustable

AC/DC

50.0~300V adjustable
Voltage hysteresis 0.1~6.0V adjustable 0.1~30.0V adjustable 1.0~90.0V adjustable

Delay time for overvoltage

and undervoltage

 0.1-999s adjustable
Reset mode Manual/ Automatic/Automatic with power-on delay
Delay time for reset 0.1-999s adjustable
Indicators LCD indicating voltage,operationand fault status
Output contacts 1 CO & 1NC
Contact capacity 6A ,250VAC
Dimensions (H x W x D) 80×43×54mm
Mounting DIN rail

24V Single Phase Relay Overvoltage Under Voltage Protection CE Passed24V Single Phase Relay Overvoltage Under Voltage Protection CE Passed

SVR1000 series single-phase over-voltage and under-voltage protector (also known as voltage monitor, over-voltage and under-voltage protector, etc.) is mainly used for 50/60Hz, rated voltage below 240V, industrial single-phase 9-300V and other voltage levels. Various fault detection provides relay protection for the voltage of the single-phase input power supply and the voltage is too low. It is an indispensable protection product for the normal working voltage of the maintenance equipment in industrial equipment operation.
