Underwater Dredging Robot

VVL-QY270-130P

Underwater robot:

Winch with cable:

Console:

Product Configuration:

Design length, width and height: 3200 * 1500 * 1550mm

Material structure: all structural parts of the body are made of manganese steel, the surface is treated with anti-corrosion and anti rust treatment, and the mobile track is made of steel.

Design weight: 3600 kg (in air)

Design total power: 45KW

Design voltage: 380VAC

Working length: 200m

Driving mode: full hydraulic

Working pressure: 16MPa

Design walking speed: 3-10 M / min

Design climbing capacity: 20 degrees

Design working water depth: 30m

One underwater slurry pump: lift 25m, horizontal transmission distance 300-500m, flow rate 92m3 / h, power 18.5kw, theoretical maximum particle diameter 45mm

Cable: 200m composite umbilical cable, able to withstand 6000kg tension

Main control system: robot control integrated cabin, separate independent control room, 4 19 inch high-intensity displays, main processor i7 control table, control lever operation. Equipped with window air conditioning.

Observation system: 5 * 2 megapixel underwater camera

Lighting system: 5 * 50W led underwater lamp

Cable winder: Electric

Sonar: M750d

Working water depth range: 1-30m

It is recommended that the continuous working time should not exceed 16 hours

Water cannon: the effective spraying distance is 10m, the flow rate is 20m3 / h, and the power is 7.5kW

Others:Equipped with back end sewage pipe, each section is 6m, total 34 sections, total 204 m

(including quick coupling)

Application:

In order to further reduce the risk of flooding during rainstorms, the Department will implement the "timely channel clearing" arrangement in the rainy season this year and actively apply new technologies to enhance the efficiency and efficiency of engineering and maintenance work. High rainfall also greatly limits the construction and maintenance of drainage facilities, affecting the ability of drainage facilities to cope with rainstorms. It can also be used to transport rainwater directly to the ground through the drainage system, which can greatly increase the efficiency of rainwater drainage. Remote control dredging robot can prevent workers from entering the closed and flooded box rainwater channel, and the dredging work does not need to be limited to the dry season.

Parts include:
