Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
Specifications
Place of Origin :
China
Brand Name :
FY-XL
Model Number :
FY-XL-15
Certification :
CCIC, ISO
Price :
9.2$/spcs
Packaging Details :
wooden box, pallet, container
Delivery Time :
3days
Payment Terms :
T/T
Supply Ability :
350pcs/day
MOQ :
200pcs
Material :
SS304, SS316L, SS321, Hastelloy C276, Titanium
Cap OD :
60mm
Screen OD :
57mm
Screen Height :
100mm
Threaded :
G-1/2" BS
Threaded Hight :
13.5mm
Total length :
137.5mm
Weight :
0.25kg
Description

Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle

Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd TRAPEZOID WIRE NOZZLES

Nozzles are an ideal solution for applications with heavy amounts of media whose weight could compromise the integrity of unsupported screens. That's because nozzles are affixed to durable steel plates that can withstand great loads without damage. Using the nozzle method gives you the reliability you want with the flow rate you require.

Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd Screens manufactures nozzles using a welded trapezoidal (wedge) wire screen variety of materials to ensure long life and reliable performance. The non-plugging, continuous slot design makes Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd Screens nozzles ideal for applications that involve the retention of sand, activated carbon, ion exchange resin and more. They withhold the media while allowing the treated liquid to pass through.

If needed, Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd Screens can also custom manufacture nozzles to your exact specifications, including material, fitting type and sizes.

Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle

Type 1: Specification of Single Head Wedge Wire Filter Nozzle

Item

Model

Slots (mm)

Outline Dimension (mm)

Filtration Area (mm2), slot 0.2 mm

D

H

L

M
1 XLSN45-1-A 0.2-0.5 45 25 75 M20 280
2 XLSN45-1-B 0.2-0.5 45 35 85 M20 390
3 XLSN45-1-C 0.2-0.5 45 45 95 M24 500
4 XLSN53-2-A 0.2-0.5 53 45 95 M24 450
5 XLSN53-2-B 0.2-0.5 53 45 95 M32 450
6 XLSN53-2-C 0.2-0.5 53 55 110 M32 550
7 XLSN57-3-A 0.2-0.5 57 35 85 M32 520
8 XLSN57-3-B 0.2-0.5 57 45 95 M32 660
9 XLSN57-3-C 0.2-0.5 57 55 110 M32 530
10 XLSN70-4-A 0.2-0.5 70 45 95 M32 530
11 XLSN70-4-R 0.2-0.5 70 70 120 M32 1000
12 XLSN82-A 0.2-0.5 82 60 120 G11/M42 /

Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle

Type 2: Specification of Double Head Wedge Wire Filter Nozzle

Item

Model

Slot (mm)

Outline Dimension (mm)

Filtration Area (mm2), Slots 0.2 mm

D

H

L

M
1 DT45-1-A 0.25-0.5 45 30 according to order M25 330
2 DT45-1-B 0.25-0.5 45 35 M25 300
3 DT45-1-C 0.25-0.5 45 40 M25 450
4 DT45-1-D 0.25-0.5 45 45 M25 400
5 DT53-2-A 0.25-0.5 53 30 M25 400
6 DT53-2-B 0.25-0.5 53 35 M25 380
7 DT53-2-C 0.25-0.5 53 45 M32 680
8 DT57-3-A 0.25-0.5 57 35-40 M32 530
9 DT57-3-B 0.25-0.5 57 50-55 M32 700-750

Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle

Type 3: Specification of Long Hand Wedge Wire Filter Nozzle

Item

Model

Slot (mm)

Outline Dimension (mm)

Filtration Area (mm2), Slots 0.2 mm

D

H

L

M

L1
1 XLLN45-11-A 0.2-0.5 45 35 35 M20 according to order 330
2 XLLN45-11-B 0.2-0.5 45 45 40 M24 400
3 XLLN53-12-A 0.2-0.5 53 35 45 M24 510
4 XLLN53-12-A 0.2-0.5 53 45 50 M32 640
5 XLLN57-13-A 0.2-0.5 57 40 45 M32 630
6 XLLN57-13-B 0.2-0.5 57 50 50 M32 780

Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle

Type 4: Specification Of Plate Type Flowing Wedge Wire Filter Nozzle

Item

Model

Slot (mm)

Outline Dimension (mm)

Filtration Area (mm2), slots 0.2 mm

D

L1

D1

L
1 CP82-DF1-A 0.25-0.5 82 50 50 130 1072-1300
2 CP82-SF1-A 0.25-0.5 82 50 50 130 551-690
3 CP82-SF1-B 1.02 82 50 50 130 1300
4 CP82-DF1-C 0.25-0.5 82 42 50 130 1020-1070
5 CP82-SF1-C 0.25-0.5 82 42 50 130 380-493
6 CP57-DF2-A 0.25-0.5 57 40 35 100 800
7 CP57-SF2-A 0.25-0.5 57 40 35 100 680
8 CP53-DF3-A 0.25-0.5 53 38 35 110 766
9 CP53-SF3-A 0.25-0.5 53 38 35 110 453-597
10 CP53-DF3-B 0.25-0.5 53 33 35 110 588
11 CP53-SF3-B 0.25-0.5 53 33 35 110 485
12 CP53-SF3-C 1.02 53 33 35 110 680-710

Johnson wedge wire water screen nozzle types:

1. Single head V wire tube flowing Screen Nozzle

2. Double head V wire tube flowing Screen nozzle

3. Long hand flowing pipe type Screen nozzle

4. Large long hand flowing pipe type Screen nozzle

5. Plate type flowing Screen nozzle

6. Double Flow Rate Screen nozzle

7. Pure round Johnson wire Screen Nozzle

Different types of wedge wire nozzles meet various application scenarios and installation requirements.

  • Single head & double head type. Used for backwash water filtration, gravity & pressure filter tanks, ion exchange filter beds and other water distribution filtration systems.
  • Long handle type. Used for the air-water backwash distribution system in filters.
  • Flat plate flow rating type. Used for the treatment of drinking water, beverages, printing and dyeing, swimming pools, and other industrial water treatments. It can also be used in industrial wastewater and domestic sewage treatment projects.

Water cap making process

stamping

Lathe parts

Wedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen NozzleWedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen NozzleWedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen NozzleWedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen NozzleWedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen NozzleWedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen NozzleWedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen NozzleWedge Wire Resin Traps, Hastelloy C276 Johnson Filter Nozzle, Titanium Screen Nozzle
