Stainless Steel Long-handle Watr Filter Nozzle Johnson Screen Mesh with Wedge Wire

Product Description:

Wedge wire screens, also known as Johnson screen mesh, are a type of metal wire mesh used for sieving and filtering. They are commonly referred to as Vee wire screens, triangular wire screens, or trapezoidal wire screens, depending on the shape of their profiled wires. This versatile structure component is widely used in various industries, including screening, dehydration, and desliming operations. Due to its high strength, stiffness, and carrying capacity, it can be made into different shapes to serve as a screening filter unit. The material used for wedge wire screens varies, commonly including stainless steel (SS205B, 304, 316, etc.), low carbon galvanized wire (LCG), mild steel wire, and iron wire.

Wedge wire screens can be found in different forms, such as wedge wire tubes/pipes (also referred to as wire-wrapped stainless steel screen pipes, water and oil well screens, changeable filter elements, screen cylinders, spiral screen pipes, strainer tubes, filter circumferences, filter drums, v wire slot tubes, screen baskets, cylindrical screens, stainless steel lateral arms, hub laterals, head laterals, etc.), wedge wire nozzles (such as water filter nozzles, johnson wire screen nozzles, and stainless steel strainer nozzles), wedge wire screen plates/pieces/flat panels (including dewatering screen panels, johnson screen plates, v wire flat panels, wire-wrapped panels, sieve bends for coal, arc screen plates, vibrating screen plates, screen plates with polyurethane frames, curved screens, and wedge wire gratings), and wedge wire screen cylinders (for applications such as rotary drum screens, DSM screens, and wedge wire filter baskets). The weaving process used for wedge wire screens is full welded, ensuring a strong and durable structure. These screens have a wide range of uses, including water wells, oil wells, mining, coal, chemicals, fertilizers, food, environmental protection, sewage treatment, food filtering, salt industry netting, and more.

Features:

Technical Parameters:

Applications:

The Oil and Gas Upstream Well Screen is an essential component in the extraction of natural resources from deep vertical wells. It is responsible for filtering out sediment, sand, and other impurities from the extracted fluid. The well screen is also used in supply wells, driven/jetted point wells, and drilled wells to ensure a steady flow of clean water.

The High Flow Municipal Well Screen is specifically designed for use in large-scale water systems, providing high flow rates and efficient filtration. It is suitable for use in a variety of industries, including municipal water treatment, petrochemicals, and thermal power plants.

For smaller-scale water systems, such as domestic water wells for residences and farms, there are various options available, including sand filters, carbon filters, and condensate polisher and ion exchange systems. These systems effectively remove impurities from the extracted water, ensuring its safety and suitability for domestic use.

In the petrochemical industry, efficient filtration is critical to maintain product quality and prevent equipment damage. Our specialized filters, including clarifiers, underdrains for media filtration, and seawater desalination systems, effectively remove impurities and ensure the purity of the final product.

In the construction industry, vibrating screen decking is used to separate and grade different materials, such as gravel, sand, and crushed stone. It is also commonly used in grain drying and fish diversion applications.

Our general industry screens cater to a wide range of screening needs, including sieve bends, cylindrical screens, centrifugal baskets, DEM screens, pressure screens, and more. These screens are suitable for various industries, such as mineral and aggregate processing, petrochemical and refining, pulp and paper, and water processing.

Our mineral and aggregate processing screens are designed for heavy-duty use in processing operations. They include vee wire centrifuge baskets, P/U modular screening systems, P/U and wire combination screens, and rubber screening systems, which provide efficient and reliable performance in challenging environments.

We offer a range of screens specifically designed for use in petrochemical and refining operations, including center pipes, outer baskets, distributor trays, nozzle systems, and scale traps. These screens effectively remove impurities and protect delicate equipment in these industries.

In the pulp and paper industry, our screens play a crucial role in various processes, such as screen baskets, extraction plates, filtrate cleaning, and fiber recovery. We also offer refurbishing services to ensure the continued efficiency and performance of our screens.

For water treatment facilities, our water process screens, including head works, dissolved air flotation (DAF), intake screens, ultra-filtration, and Triton underdrains, are essential for ensuring clean and safe water for the community.

Our water well screens are designed for use in both stainless steel and PVC pipes, providing reliable and efficient filtration for various applications. They can also be used in conjunction with riser pipes, sand spears, and environmental monitoring screens, and can be treated with our Nu-well rehabilitation chemicals to prolong their lifespan.

Customization:

Xinlu brand customized johnson screen mesh, available in model number from 1" to 40", is designed and manufactured by Anping County Xinlu Wire Mesh Products Co.,Ltd with high precision and expertise. Our product is made from high-quality materials and has various certifications including CO, FORM E, FORM F, and SGS. It is the perfect solution for a wide range of industrial and commercial applications.

• Brand Name: Xinlu
• Model Number: Customized 45mm-82mm
• Place of Origin: Anping County Xinlu Wire Mesh Products Co.,Ltd
• Certification: CO, FORM E, FORM F, SGS
• Minimum Order Quantity: 10pcs
• Packaging Details: inside transparent plastic bag, outside woven bag, or bubble bag, or wooden box, or pallet
• Delivery Time: 5-20days according to the order quantity
• Payment Terms: T/T, cash, or others
• Wire Shape: V Shape, Wedge Wire Shape, Round Wire Shape
• Key Words: Wedge Wire Screen, V Wire Screen, Johnson Wire Screen, Mine Screen Mesh
• End Connection: Threaded, Welded Rings, Flange
• Screen Pipe Shape: Wedge Wire Screen Tube/pipe, Wedge Wire Screen Nozzle, Wedge Wire Screen Cylinder, Wedge Wire Screen Basket And Wedge Wire Screen Wedge Wire Screen Plate/panel
• Strength: High Mechanical Strength

Our customized Johnson screen mesh is available in various options to meet your specific needs and requirements. We provide customized services for wire shape, end connection, and screen pipe shape. Our team of experts will work with you to ensure that our product meets your exact specifications and delivers the best performance.

Key Words: Spiral wire wrapped screen pipe, Johnson wire screen pipe, Johnson wire screen pipe filter, Wedge wire screen, V wire screen, Mine screen mesh, Customized service, High mechanical strength

Packing and Shipping:

Johnson screen mesh is typically packaged and shipped in wooden cases or pallets to ensure safe delivery to customers.

Each piece of screen mesh is carefully inspected and wrapped with protective materials to prevent damage during transit.

Our standard shipping method is by sea, but we are also able to arrange air or land transportation upon request.

The approximate delivery time for Johnson screen mesh is 15-30 days, depending on the quantity and destination.

Please contact us for any special packaging or shipping requirements.
