Washable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing Times
Washable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing Times
Washable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing Times
Washable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing Times
Specifications
Brand Name :
WS
Model Number :
RFID UHF Laundry Tags
Certification :
ROHS,REACH,POPS
Place of Origin :
CHINA
MOQ :
200-500pcs
Payment Terms :
TT,PAYPAL,WU
Supply Ability :
1,000,000pcs per month
Delivery Time :
5-7days
Packaging Details :
1g/pc, 100 pcs / sealed bag, 105g/bag, 40 bags/carton
Frequency :
860-960mhz,UHF860-960MHz/915MHz
material :
Textile
Protocol :
ISO 18000-6C,ISO18000-6C or EPC class Gen2
Printing :
Plain White/Color Printing/Silk Printing/Logo Printing
Product Name :
RFID UHF Laundry Tags
Antenna Size :
customized
Write Endurance :
100, 000 cycles
Antenna Material :
Aluminum
Chip :
Alien H3/H4,UHF,Monza 5
Reading distance :
UHF 1.5~10m
Description

Washable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing Times

RFID clothing warehouse system uses advanced RFID tag has a globally unique identifier encoded. RFID tag support long-range identification

Do not read and bulk, with a strong environmental adaptability and other characteristics. In the production process, the first use of RFID card issuing machine some important single piece of clothing


Property write RFID tag, and the tag attached to the corresponding clothing, combined with fixed readers, handheld readers and other data mining


Collection means for the storage of clothing for automatic identification and data collection, automatic inventory quickly grasp the stock quantity, monitor inventory assets,


Enables fast positioning and timely delivery. Meanwhile dozens of pieces added a RFID tag reader FCL disposable clothing can accurately read
Whichever all the data, greatly improving the efficiency of storage management.

Washable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing Times
With the development of the global economy, many hotels, hospitals, baths and related washing companies are facing the process of handling thousands of work clothes, linen washing, ironing, finishing and storage. The development of technology has enabled the market for linen washing labels to be continuously automated and intelligent.
For the washing shop, it is necessary to distinguish the different types of textiles and textile cleaning times of different hotels, and also need to solve the problem of quick cleaning of washing products, storage and storage list when washing and delivering linen.
In order to ensure the accuracy of the quantity of linen washing products and improve the efficiency of linen washing work, garment washing plants and dry cleaning washing shops are using RFID labels with linen.

The advaes of UHF laundry tag

1.Trace the clothes throughout its complete cycle of its arrival in the laundry to its dispatch.
2. Multiple tags can be read simultaneously.
3.The tags are robust, water proof, and can stand up to all kinds of changes in environmental conditions in terms of heat, humidity, pressure, resistance caused due to water and other chemicals

RFID UHF Laundry Tags
RFID Standard ISO/IEC 18000-6 TypeC (EPC Gen2)
Size & Weight 88(W)x4.0(D)x4.0(H)mm, 1.85 g
Chip Type Alien Higgs-3,MR6,U CODE7
EPC Memory 96 bits to 480 bits
User Memory 512 bits
Reading Range 902-928 MHz 3.0-7.0m
866-868 MHz 3.0-6.0m
Tagging Sewing, Insert.
Estimated Lifetime 225 washing cycles or 3 years, whichever comes first
Environmental Resistance(1) Washing Method Laundry, Dry cleaning
(2) Water Extraction Pressure 60 bar
(3) Water Resistance Water resistant
(4) Chemical Resistance Detergent, Softener, Bleach (Oxygen/ Chlorine), Alkali
(5) Heat Sterilization 125 ºC for 15-20 minutes - 150 cycles
(6) Heat Resistance Drying

85°C (Up to 60min.)

120°C (Up to 30 min.)
Ironing 230°C (Up to 60 sec. with press cloth)
Humidity/ Temperature Operating -20 to 50°C, 10 to 95%RH
Storage -40 to 55°C, 8 to 95%RH

How STRONG they are ?

①.Are the RFID chips be damaged under high temperatures? – Our RFID textile laundry tag are designed to be used at 200 °C.

②How many times can we wash the tags that are attached to uniforms textile products? –Our RFID textile laundry tag can be washed more than 200 times guaranteed for 2 years after shipping.
③Are we going to spend prestigious uniforms textile products, continue to work in case of chip crush? –We designed our textile laundry tag to withstand 60 bars of pressure in the process of pressing your textile products.
④Where do you place RFID textile laundry tags on uniforms textiles? – RFID textile laundry tag are installed according to the availability of the uniforms.

Washable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing TimesWashable Heat Seal RFID Laundry Tag UHF UC ODE 8 Chip Over 200 Washing Times

Physical
MAXIMUM TEMPERATURE EXPOSURE:
220℃ (392℉) |30Seconds | 2.5 bars(36,28PSI)
WASHING:
100℃ (194℉) | 60minutes 120Bar
PRE-DRYING IN TUMBLER:
160℃ (320℉) | 30minutes
TUNNEL FINISHER:
185℃ (365℉) | 30minutes 185℃ (365℉) | 30minutes
STERILIZATION PROCESS:
134℃ (273℉) | 20minutes
WATER EXTRACTOR PRESS:
120bars
WARANTY:
250cycles or 3years (New Encapsulation)
Three ways of using RFID Laundry Tag:
Sack
Ironing
Sewing

Q&A

Q1: I’m interested in your products, but now I’m out of China; could you offer you labels to my country?
A1: Sure! We’ve got full exportation experience, and no matter where you are, we may arrange the delivery for you, either by sea, by air or by express, depending on your need.

Q2: How can I get the samples?
A2: We can provide you free sample for our existing products, the lead time is around 1-2 days. You need to pay for the sample delivery cost.
If you need the samples according to your design, the sample cost has to be charged from you. The lead time is around 5 days.

Q3: Is it possible to custom the labels with my own design?
A3: Yes, and you just need send us your drawings or artworks, then you can get what you want.

Q4: What is your MOQ?
A4: For label stickers, the MOQ is 1000 pcs for each design.
For thermal transfer ribbon, the MOQ is 10 rolls for each type and size.

Q5: Do you provide OEM service?
A5: Yes. Actually, we’re already OEM for some brand, and also do the specific packing for them.

Q6: What is your manufacture lead time for our order?
A6: Our normal lead time is 15-20 days. If you have urgent request, please just let us know. We will try our best to shorten the lead time to meet your requirements.

Q7: How can I release the payment to you?
A7: We can receive your payment by Paypal, Western union or Bank Account.
