High Safety Home Gas Boiler , Wall Mounted Propane Boiler Easy Operation
High Safety Home Gas Boiler , Wall Mounted Propane Boiler Easy Operation
High Safety Home Gas Boiler , Wall Mounted Propane Boiler Easy Operation
High Safety Home Gas Boiler , Wall Mounted Propane Boiler Easy Operation
High Safety Home Gas Boiler , Wall Mounted Propane Boiler Easy Operation
High Safety Home Gas Boiler , Wall Mounted Propane Boiler Easy Operation
Specifications
Brand Name :
Dongyuan
Model Number :
L1PB24-HY
Certification :
ISO14001,ISO9001,OHSAS18001
Place of Origin :
China,Shunde
MOQ :
Negotiable
Price :
USD230-250pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10000pcs per month
Delivery Time :
30days after receiving the deposit
Packaging Details :
Each product in plastic bag which comes with the product instructions and foam packaging, then carton packaging outside with another thicker plastic bag.
Gas Type :
NG
Output power capacity :
16-28kw
Exchanger :
Two Heat exchanger
roduct dimension(mm) :
740mm*400mm*305mm
Packing dimension(mm) :
860mm*470mm*395mm
Description

Wall Mounted Style Wall Hung Gas Boiler For Apartment And Water Heating

Technical data

Model Number L1PB16 LIPB18 L1PB20 L1PB24 L1PB32 L1PB36
Gas Type NG/LPG
Rated Gas Pressure(Pa) 2000/2800
Rated Gas Input(kw) 16 18 20 24 32 36
Rated Gas Output(kw) 14.1 15.9 17.6 21.1 28.2 31.7
Efficiency Under Rated Heat Input(%) Above88%
Power Supply 20-50HZ
Electric Power(W) 110 110 110 110 145 145
Temp.Range Of Heating Water(℃) Radiator:30-80 Floor Heating:30-60
Heating Area(㎡) 60-120 70-140 80-160 100-200 200-300 200-300
Lift Of pump(m) 5 5 5 5 7 7
Application Water Pressure(Mpa) 0.1-0.3
Expansion Tank Capacity(L) 6 6 6 6 8 8
Preset Pressure Of Expansion Vessel(Mpa) 0.1
Water Circulation Type Airtight Forced Circulation
△T=25℃ Hot Water Supply(kg/min) 8 9 10 12 16 18
△T=30℃ Hot Water Supply(kg/min) 6.7 7.5 8.3 10 13.3 15
Temp.Range Of DHW Supply(℃) 30-60
Applicative Water Pressure(mpa) 0.03-0.8
The Minimum Starting Flow (L/min) 2
The Minimum Closed Flow(L/min) 1.6
Connections(mm) For Gas&Heating Water Pipes:G3/4 For DHW Pipes:G1/2
Air Input/Exhaust Duct(mm) φ60/φ100
Sparated Input/Exhaust Duct(optional) φ80/φ100
The length Of Flue Dust(m) 1
Noise On Working(DB) ＜42
Exhaust Type Forced Exhaust
Ignition Type Integrated Automatic Ignition
Temperature Control Gas Proportional Adjustment
Product Dimensions(mm) 740*400*305 855*470*390
Packing Dimensions(mm) 865*470*385 870*495*390
Container(20GP/40GP/40HQ) 17//357/434 166/333/404

- Solid chamber structure design reduces combustion noise.

- Multiple automatic protections.

- Gas flow proportional control,provide sable heating temperature.

- Micro-computer control and self-inspection system.

- Proportional controlling of gas flow, and heating with frequency conversion.

- LCD display showing the actual working condition.

- Fashionable flat panel design, easy to operate.

- Water flow and temperature double control, provides stable domestic hot water temperature.

- Proportional controlling of gas flow, and heating with frequency conversion.

- With digital LED display and all working condition is clear.

- With function of heating and domestic hot water to be used freely.

- With design of stable wind resistance, and the boiler works stably even in bad weather.

- With overtime protection when time for constant domestic hot water is more than 60 minutes,and the bath would be more safe.

- With special mode of floor heating as 60℃ limited temperature protection, and be more comfortable.

- With special device of explosion protection to protect the boiler.

- With 20 kinds of safe protection to protect your while family.

-With selectable device of indoor thermostat, the indoor temperature would be set freely and 20% energy saving.

-Popular model to export more than 20 countries.

Features:

- Anti-lock function for pump.

- Water pressure monitor function of heating circulation

- Flame out protection.

- Automatic by pass function for pump and control system.

- Reignition function.

- Self diagnostic function

- Wind pressure safety protection

-Twice Anti freezing function.

- Overheat protection for domestic hot water.

- Defer ignition function.

-Automatic circulation function of pump.
