60HZ 220V R410a R22 Slim Wall Mounted Air Conditioner 12000BTU Cooling Heating
60HZ 220V R410a R22 Slim Wall Mounted Air Conditioner 12000BTU Cooling Heating
Specifications
Brand Name :
YUETU or OEM
Model Number :
12000BTU
Certification :
CE/BC
Place of Origin :
CHINA
MOQ :
100pcs
Price :
$130
Payment Terms :
L/C, , T/T
Supply Ability :
10000pcs/month
Delivery Time :
35 work days after receipt of the deposit
Packaging Details :
Standard export carton box package suitable for container shipment.
Factory :
San Ming City
Port :
Xiamen Port
Label :
OEM Label
Brand :
OEM/YUETU
EER :
2.5~3.5
Capacity :
7k~32k
Description

60HZ 220V R410a R22 Slim Wall Mounted Air Conditioner 12000BTU Cooling Heating​

CA Panel 60HZ 220V R410a/R22 12000BTU Cooling Heating High Quality Wifi Control PCB 3 Year Warranty


Dehumidification
The air conditioner is accompanied by dehumidification during the refrigeration process. The relative humidity of the environment that people feel comfortable should be around 40-60%. When the relative humidity is too high, such as above 90%, even if the temperature is within a comfortable range, people still feel bad.
Purifying air
The air contains a certain amount of harmful gases such as NH3, SO2, etc., as well as various odors such as sweat, body odor and bathroom odor.

12000BTU
Model No.TAC-12CS/ZTAC-12CHS/Z
KF-35GWKFR-35GW
内820(Φ7×2)+780(Φ7.94×1)indoor 820(Φ7×2)+outdoor 780(Φ7.94×1)
Typecooling onlyHeating Pump
Control type
Rated cooling capacityBtu/h;W12,00011535;3381
Rated heating capacityBtu/h;WN.A12552;3679
EER for coolingBtu/h.w; W/W10,2.92.7
COP for heatingW/WN.A3.67
Moisture removalLiters/h11.3
PressureHigh(DP)MPa2.82.6
Low(SP)MPa1.21
Indoor noise level at coolingHighdB(A)4141
Med.dB(A)3737
LowdB(A)2424
Outdoor noise leveldB(A)5252
Power supply
Voltage RangeV198~242198~242
Rated currentCoolingA5.65.8
HeatingAN.A5.3
Rated inputCoolingW12001253
HeatingWN.A1163
Annual energy consumptionkwh (cooling)
Max CurrentCoolingA7.39.8
HeatingAN.AN.A
Max Power inputCoolingW15601790
HeatingWN.AN.A
Refrigerant/ChargeGramR22R22
CompressorTypeRotaryRotary
Model/C-RV212H92CB/QX-B217E030A
LRAA//
MFG/SANYO/GREE
Indoor air circulation(Cooling/Heating)m3/h530530/530
Indoor fan typeCross FlowCross flow
Indoor fan speed H/M/LCoolingrpm1270/1170/10001290/1150/900
HeatingrpmN.A1290/1150/900
Dryrpm1000900
Sleeprpm1000900
Indoor fan motor outputW1213
Outdoor fan typePropellerPropeller
Outdoor fan speedrpm860850
Outdoor fan motor outputW4530
Connecting PipeGasmmΦ12(1/2'')Φ12
LiquidmmΦ6(1/4'')Φ6
Connecting WiringSize x Core number1.0x3; 0.75x21.0*5
Drainage Pipe
Suitable aream215~2312~23
Net dimensions (W x H x D)Indoormm820x250x205820x250x205
Outdoormm780x540x255780x540x255
Net weightIndoorkg810.5
Outdoorkg3436
Packing dimensions (W x H x D)Indoormm855x305x255880*315*269
Outdoormm863x598x376870*340*590
Gross weightIndoorkg1011.5
Outdoorkg3838


Maintenance
Maintenance before starting up
Generally, household air conditioners are turned off in September and then turned on from May to June of the following year. They will not be used for more than half a year. Therefore, a comprehensive "diagnosis" must be done before the air conditioner is turned on to check whether the air conditioner is "faulty". According to the results of the inventory, under the guidance of professional and technical personnel, do a good job of maintenance and cleaning. This time, the maintenance and cleaning should be more in place. Including the casing, body, and filter of the outdoor unit and the indoor unit, and then start trial operation to observe the cooling speed and effect.

cleaning method
The cleaning of the air conditioner should include three parts:
First, the casing and exposed parts of the air conditioner body, which are easily contaminated parts;
Second, filter cleaning is the most important part of the core;
Third, the condenser and evaporator part
