Mppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPS
Mppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPS
Specifications
Brand Name :
Kweight
Model Number :
SPH6000TL BL-UP
Certification :
CE/RoHS/UN38.3/MSDS
Place of Origin :
China
MOQ :
1 Pieces
Payment Terms :
L/C, D/A, T/T, D/P, Western Union, MoneyGram
Supply Ability :
10000 Pieces per Month
Delivery Time :
30 days
Packaging Details :
Standard Packing
Input Voltage :
120V-550V
Output Voltage :
220V
Output Current :
27A(Max)
Output Frequency :
50,60Hz/±5Hz
Output Type :
Single
Size :
458/565/188mm (W/H/D)
Type :
DC/AC Inverters
Inverter Efficiency :
97.5%(Max.efficiency)
Weight :
31kg
Warranty :
years
Description
6000W MPPT 230V Pure Sine Wave Solar Inverter For On Grid Tie System With UPS Function SPH6000TL BL-UP
Product features:
>UPS function, 10ms transition
>4kW charge/discharge power
>4kw backup power
>AC-coupled function compatible with third-party inverter
>1.5 DC/AC ratio, 6kw system with 9kW solar input
>13.5A solar input current for high power modules
>VPP interface ready
>Scalable system configuration
>Safety standard set by LCD directly
Datasheet
SPH3000
SPH4000
SPH4600
SPH5000
SPH6000
PV Input data
Max. recommended PV power (for module STC)
6600W
8000W
9200W
10500W
11200W
Max. DC voltage
550V
Start voltage
120V
MPP voltage range
120V-550V/360V
No. of MPP trackers
2
No. of PV strings per MPP tracker
1
Max. input current per MPP tracker
13.5A
Max. short-circuit current per MPP tracker
16.5A
AC Output
Rated AC output power
3000W
4000W
4600W
5000W
6000W
Max. AC apparent power
3000VA
4000VA
4600VA
5000VA
6000VA
Nominal AC voltage (range)
230V/(180Vac-270Vac)
AC grid frequency (range)
50Hz/60Hz (45Hz-55Hz/55Hz-65Hz)
Max. output current
16A
22A
22A
22A
27A
Displacement power factor
0.8leading…0.8lagging
THDI
< 3 %
AC grid connection type
Single phase
AC output power(Backup)
Max. output power
3000W
3000W
3000W
3000W
3000W
Max. output current
17.4A
Rated AC output voltage
230Vac
Rated AC output frequency
50/60Hz
THDv
<3%
Switch time
<10ms
Battery data
Battery voltage range
42~59V
Max charging and discharging current
66A
85A
85A
85A
85A
Max charging and discharging power
3000W
4000W
4000W
4000W
4000W
Type of battery
Lithium /Lead-acid
Efficiency
MAX. efficiency
97.2%
97.3%
97.4%
97.5%
97.6%
Euro European efficiency
97.0%
97.1%
97.1%
97.2%
97.2%
MPPT efficiency
≥99.5%
Protection devices
DC switch
yes
DC reverse polarity protection
yes
AC/DC surge protection
yes
Battery reverse protection
yes
Output over current protection
yes
Output over voltage protection
yes
Ground fault monitoring
yes
Grid monitoring
yes
Integrated all - pole sensitive leakage
yes
General data
Dimensions (W / H / D)in mm
458/565/188mm
Weight
31kg
Operating temperature range
-25°C... +60°C
Nighttime power consumption
< 10 W
Topology
transformerless
Cooling
Natural
Protection degree
IP65
Altitude
2000m
Relative humidity
0~100%
PV DC Connection
MC4/H4(opt)
Battery DC Connection
OT Terminal
AC connection
Connector
Interface:RS232/USB/RF/Wi-Fi
yes/yes /opt/opt
Display
LCD+LED
Interfaces:RS485/CAN/USB
Yes
Monitor : RF/WIFI/GPR
Optional
Warranty: 5 years /10 years
yes / opt
Mppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPSMppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPSMppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPSMppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPS
Company Profile
Shenzhen Kweight Development Co., Ltd. is one of the leading lead-acid battery manufacturer in China. Our factory is located in Longgang District of Shenzhen & Yangquan, Shanxi in China and covers an area of 50,000 square meters. There are over 200 workers and 15 members in charge of engineering, management and quality control.Our company specializes in manufacturing 2V, 4V, 6V and 12V series maintenance free lead-acid battery, Gel battery, Deep cycle battery, solar battery, front access(gel) battery, OPzV and OPzS battery etc.. We have hundreds of models and specifications for selection, and all of products are compliance with CE, RoHS and UL. Our quality is strictly controlled as per ISO9001:2008 quality system and every piece of our battery is inspected by advanced testing machines before shipment. Our batteries are exported to North America, South America, East & West Europe, Australia & Africa relying on their good quality and competitive prices.Please feel free to contact us for further information.
Mppt 6000 Watt Grid Tie Inverter 230v Grid Hybrid Solar Power Inverter With UPS
FAQ
Q1:Are you a manufacturer or trading company?
A: We are a manufacturer, a leading company in the global battery field.
Q2:How about your after-sale service?
A: We can offer you timely and best after-sale service. So far we have our branch offices in many overseas countries like USA, Canada, the UK, France, Brazil, Japan, Korea, Philippines, Malaysia, India, Australia, and other Asia and African countries. It makes our after-sale service very easy and effective to reachyou. Also our 24 hours online inquiry service is available.
Q3:What's your delivery time?
A: It depends on the specific products and the quantity you need.
Q4:What certifications does your company have?
A: Our company had passed the CE&RoHS, ISO19001&ISO14001 certifications.
Q5: Why should I choose your company?
A. Our belief : assured long-lasting quality, reliable long-existing service.

B. Our competence: quality and technology is our key competitive advantage, wins a good reputation and track record for us.
C. Our dream: provide every customer with the suitable high quality battery for the further business cooperation.
D. Our honor : our batteries served as the power supplier for 2010 Singapore Youth Olympic Games for their reliable quality and stable high performance
