15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color
15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color
15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color
15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color
15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color
15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color
Specifications
Brand Name :
Fullpower
Model Number :
20220
Certification :
FCC,UL,CE,UKCA,SAA,KC,PSE,CCC,etc
Place of Origin :
China
MOQ :
1000PCS
Payment Terms :
T/T, Western Union
Supply Ability :
100000PCS/Day
Delivery Time :
30 working days
Packaging Details :
Individul Pe Bag Packing or others
Item :
36W Wall-mount Power Adapter
Input :
100-240V 50/60HZ
Output :
DC 36W Max
Material :
ABS+PC
Color :
Black, White Or Others
Protection :
OCP, OLP, OVP And Others
Logo :
Fullpower Or Custom Make
Warranty :
3 Years
Description

36W 15 Minute Battery Charger 2 Bay 18650 Battery Charger D Cell Battery Charger Aa Aaa Battery Charger

Certification
Factory IS09001, ISO14001, BSCI
EMS EN55022, EN55014, EN55032, EN55035, EN61000
LVD EN62368, EN61558, EN60335
UKCA EN62368, EN60335, EN61558
GS IEC62368, IEC60335
CB IEC62368, IEC60335
UL/cUL UL62368, UL1310
FCC FCC Part 15
PSE J60335, J55014, J3000, J62368
SAA AS/NZS 60950, AS/NZS 61558, AS/NZS 62368
IRAM IEC60950

Data-sheet

FEATURES SAFETIES APPROVALS PRODUCTS PICTURE

v EFFICIENCY VI

v 30-36 WATT OUTPUT POWER

v OVERCURRENT PROTECTION

v SHORT CIRCUIT PROTECTION

v INPUT PROTECTION

v ROHS COMPLIANT

US Type

v UL

v CB

v FCC

v ROHS

v REACH

 15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color
TYPICAL MODEL LIST
I/P Voltage Typical model Output Voltage Output Current Ripple & noise Efficiency Level

90 - 264V

47 - 63HZ

 SAW36E-050-4000 5V 4000mA 90mV VI SIX
SAW36E-050-5000 5V 5000mA 90mV VI SIX
SAW36E-050-6000 5V 6000mA 120mV VI SIX
SAW36E-180-2000 18V 2000mA 120mV VI SIX
SAW36E-120-3000 12V 3000mA 150mV VI SIX
SAW36E-240-1500 24V 1500mA 150mV VI SIX
INPUT SPECIFICATIONS GENERAL SPECIFICATIONS
Input Voltage 90〜264VAC Primary to Secondary 50MΩ MIN
Input Frequency 47〜63Hz Efficiency VI
Input Current 1.3A Max Standby Power 0.3W MAX
Inrush Current 40A Max Leakage Current 0.25mA MAX
OUTPUT SPECIFICATIONS ENVIRONMENTAL SPECIFICATIONS
Output Voltage Range 5V-48V Operating Temperature 10°C~40°C
Output Current Range 100mA-6000mA Cooling Convection
Output Power Range 48.0W Max Temperature Coefficient 0.05%/°C
Short Circuit Protection Automatic Recovery Humidity 5~95%RH(non-condensing)
Over-Current Protection Automatic Recovery Storage Temperature -20°C~+80%°C
Ripple and Noise 100mVp-p max PHYSICAL SPECIFICATIONS
Turn On Time 20-30mS normal Physical Specifications 97.5mm *50.5mm *32.5mm
Line Regulation 1% max SAFETIES STANDARD
Output Regulation ±5% Safeties Standard 62368 / 60950/ 60335/ 61558/ 60065

Product Pictures

15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color

15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color

15 Minute AA AAA 2 Bay 18650 Battery Charger D Cell 36W Black Color

FQA

Q: What is your advantage?
A : Our price is cheaper 20% than same level factory.
Q: What is the payment methord ?

A: T/T, L/C, Western Union, PayPal.
Q: What about your quality?
A : Less than 0.1% defective rate, more that 3 years warranty.
Q : What about your lead time?
A : About 30 days, urgent order will try to push ahead.
Q: What about sample?
A: Sample lead time is about 5-7 days, less value sample can be free.
