120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette
120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette
120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette
120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette
Specifications
Brand Name :
Fullpower
Model Number :
17110
Certification :
FCC,UL,CE,UKCA,SAA,KC,PSE,CCC,etc
Place of Origin :
China
MOQ :
500PCS
Payment Terms :
T/T, Western Union
Supply Ability :
100000PCS/Day
Delivery Time :
30 working days
Packaging Details :
Individul Pe Bag Packing or others
Item :
120W Wall-mount Power Adapter
Input :
100-240V 50/60HZ
Output :
DC 120W Max
AC Socket :
C6 C8 C14
DC connector :
Custom make
Material :
ABS+PC
Color :
Black, White Or Others
Protection :
OCP, OLP, OVP And Others
Logo :
Fullpower Or Custom Make
Warranty :
3 Years
Description

120w Plug In Battery Charger Aa Battery Recharger Electronic Cigarette Battery Charger

Certification
ISO14001, ISO9001, BSCI
SAA, RCM, C-TICK, CCC, BSMI, BIS, KC, KCC, PSE, ECA, CE, CB, UKCA, GS, UL, FCC

Data-sheet

FEATURES SAFETIES APPROVALS PRODUCTS PICTURE

v EFFICIENCY VI

v 100-120W OUTPUT POWER

v OVERCURRENT PROTECTION

v SHORT CIRCUIT PROTECTION

v INPUT PROTECTION

v ROHS COMPLIANT

Desktop Type

v UL, FCC

v CB, CE, UKCA

v CCC, KC, PSE

v SAA

v REACH, ROHS

 120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette
TYPICAL MODEL LIST
I/P Voltage Typical model Output Voltage Output Current Ripple & noise Efficiency Level

90 - 264V

47 - 63HZ

 CGSW120D-120-10000 12V 10000mA 30mV 6 Level VI
CGSW120D-150-8000 15V 8000mA 40mV 6 Level VI
CGSW120D-180-6666 18V 6666mA 50mV 6 Level VI
CGSW120D-200-6000 20V 6000mA 70mV 6 Level VI
CGSW120D-360-3333 36V 3333mA 50mV 6 Level VI
CGSW120D-480-2500 48V 2500mA 50mV 6 Level VI
INPUT SPECIFICATIONS GENERAL SPECIFICATIONS
Input Voltage 90〜264VAC Primary to Secondary 50MΩ MIN
Input Frequency 47〜63Hz Efficiency VI
Input Current 1.5A Max Standby Power 0.5W MAX
Inrush Current 40A Max Leakage Current 0.25mA MAX
OUTPUT SPECIFICATIONS ENVIRONMENTAL SPECIFICATIONS
Output Voltage Range 12.00V-48.00V Operating Temperature 10°C~40°C
Output Current Range 100mA-10000mA Cooling Convection
Output Power Range 120W Max Temperature Coefficient 0.05%/°C
Short Circuit Protection Automatic Recovery Humidity 5~95%RH(non-condensing)
Over-Current Protection Automatic Recovery Storage Temperature -20°C~+80%°C
Ripple and Noise 100mVp-p max PHYSICAL SPECIFICATIONS
Turn On Time 20-30mS normal Physical Specifications 172.4mm *72.4mm *33.4mm
Line Regulation 1% max SAFETIES STANDARD
Output Regulation ±5% Safeties Standard 62368 / 60950 / 60335 / 61558 / 60065 / UL1310

Product Pictures

120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette

120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette

120W AA Plug In Battery Charger Wall Mount For Electronic Cigarette

ABOUT Yingyuan:

Since 2006-----rich experience and professional in adapter field
As a leading manufacturer of AC adapter and transformer in Shenzhen, China, Yingyuan has been specialized

in power supply products for over 14 years.
Focusing on AC adapter marketing and manufacturing, Yingyuan has scientific, intact and efficient quality

management system, which extends from product designing, raw material control, on-spot production

management to after-sale services with constant, stable and reliable quality assurance.
ISO9001:2008 system is fully implemented in our management. Our products have passed most of safety

approvals in the world, including UL, cUL, FCC, PSE, GS, CE, SAA, CCC, C-tick, CB, etc.

Welcome to visit our company for further information!

FQA

Q: Are you a manufacturer?
A: Of course we are a famous manufacturer which in ShenZhen,China found in 2005.Welcome to visit our factory in any time.
Q: How about warranty?
A : We offer 3 years Warranty.
Q: How can I finish my payment?
A: T/T, L/C, Western Union are all acceptable, PayPal is also OK.
Q : what is the lead time ?
A : Samples are 3-5 days . Mass products Usurally 25-30 working days
Q: How about sample? For free?
A: YES! Generally we offer 1-3PCS sample(s) for your test FOR FREE, but you need to bear the freight cost.
