1 Ton Semi Electric Pallet Stacker 3m Lifting Height With Strong Fixed Forks
1 Ton Semi Electric Pallet Stacker 3m Lifting Height With Strong Fixed Forks
1 Ton Semi Electric Pallet Stacker 3m Lifting Height With Strong Fixed Forks
1 Ton Semi Electric Pallet Stacker 3m Lifting Height With Strong Fixed Forks
1 Ton Semi Electric Pallet Stacker 3m Lifting Height With Strong Fixed Forks
1 Ton Semi Electric Pallet Stacker 3m Lifting Height With Strong Fixed Forks
Specifications
Brand Name :
REACH
Model Number :
CDD1030B-III
Certification :
CE
Place of Origin :
Zhejiang, China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
200 sets per month
Delivery Time :
25 - 30 days
Packaging Details :
1set / pallet
Capacity :
1ton
Max. lifting height :
3m
Lowered mast height :
2.09m
Extended mast height :
3.06m
Tyre size, front :
180*50mm
Tyre size, rear :
80*70
Fork dimension :
60/170/1070mm
Service weight :
480kg
Description

1ton 3m electric pallet stacker semi type with strong fixed forks CE certification

Quick Details:

Description: electric pallet stacker semi type CDD1030B-III

Capacity: 1000kg

Lifting height: 3000mm

Aisle width for pallets 800*1200 lengthways: 2267mm

Service brake: mechanical

Battery: 12V120AH

Advantages:

  • ​​​Chain auxiliary device effectively reduces labor intensity.
  • Explosion proof valve ensures smooth down of the forks and protects operator's safety.
  • The over discharge protection device greatly prolongs the use time of the battery.
  • Adjust forks can move to the same height as the leg.
  • The foot brake is simple to operate.

Option:

  • ​​​Change to straddle legs
  • Change to adjustable forks.
  • Different capacity 1500kg.

SPECIFICATIONS
Model Fixed type forks
CDD10B-III
Load capacity kg 1000
Load center distance mm 500
Load distance, centre of drive axle to fork mm 802
Tyre size, front mm 180*50
Tyre size, rear mm 80*70
Height, mast lowered mm 1840
Max. lifting height mm 2500
Extended mast height mm 3060
Overall length mm 1678
Length to face of forks mm 608
Overall width mm 800
Fork dimensions mm 60/170/1070
Width overall forks mm 580/695
Aisle width for pallets 800*1200 lengthways mm 2267
Turning radius mm 1425
Lift speed, laden/unladen m/s 0.08/0.1
Lowering speed, laden/unladen m/s 0.15/0.12
Service brake mechanical
Battery V/Ah 12/120
Service weight kg 460
