Customized Waste Material Sorting Machine Ballistic Separator Double Stage
Customized Waste Material Sorting Machine Ballistic Separator Double Stage
Customized Waste Material Sorting Machine Ballistic Separator Double Stage
Customized Waste Material Sorting Machine Ballistic Separator Double Stage
Customized Waste Material Sorting Machine Ballistic Separator Double Stage
Customized Waste Material Sorting Machine Ballistic Separator Double Stage
Specifications
Brand Name :
Hengyang
Model Number :
HC-204
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
3200-45210USD/set
Payment Terms :
T/T
Supply Ability :
300Sets/month
Delivery Time :
20 days
Packaging Details :
Negotiated
Name :
Ballistor Separator
Application :
MSW Waste
Function :
Separating RAW MATERIAL
Condition :
New
Color :
Customized
Description

Hengyang designs and builds single-stage and double stage ballistic separator. These separators are placed upstream of sorting plants and allow you to make the separation of the treated materials by exploiting the different physical properties which they own. They have the function of separating the feed stream into three streams based on the technological principle according to which the separation of the individual parts placed in a current of fall takes place according to the different flight curves.

The fed material falls on an inclined bottom and rotating, by the rotational movement, transmits a pulse and generates a movement of flight contrary of the individual parts; at this stage the individual parts behave differently; light fractions (flat and thin), such as paper, cardboard medium sized, plastic film, textiles and so on, are thrown upwards along the trajectories flat and low and transported by the rotary movement of the base towards the top of machine, in the direction of the upper hopper arranged to light fractions; heavy fractions (cubic – solid) are thrown upwards by the movement of the bottom and flow from the inclined position of the same in a position of flight directed downwards of the machine where is located the discharge hopper.

This screening process therefore generates three fractions: the fraction sieved, the light fraction and the heavy fraction which are then conveyed to the subsequent steps of the selection process.

Customized Waste Material Sorting Machine Ballistic Separator Double Stage

Waste Material Ballistic Separator Application

  • 3D materials - rolling and heavy materials, like: hollow bodies, different packages, plastic bottles, stones, wood, cans and steel sections;
  • 2D materials- flat and light materials, like: plastic films, textiles, paper, cardboard and fibers;
  • Fine fraction - screened fraction of various sizes can be separated according to paddle perforation.

Hengyang Ballistic separators is ideal for processing: plastic mixed with paper, films, cans and fine-sized material, as well as for municipal solid waste, commercial and industrial waste.
