Activated Carbon Rotary Kiln Lime Zinc Contenting Waste Material Kiln Furnace
Activated Carbon Rotary Kiln Lime Zinc Contenting Waste Material Kiln Furnace
Activated Carbon Rotary Kiln Lime Zinc Contenting Waste Material Kiln Furnace
Activated Carbon Rotary Kiln Lime Zinc Contenting Waste Material Kiln Furnace
Specifications
Brand Name :
Hengyang
Model Number :
HC-167
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
5200-69120USD/set
Payment Terms :
T/T
Supply Ability :
300Sets/month
Delivery Time :
20-60 days
Packaging Details :
Negotiated
Condition :
New
After-sales service provided :
Engineer oversea service
Application :
Zinc Contenting Waste Material Recovery
Warranty :
TWO YEARS
Product name :
Zinc Contenting Waste Material Recovery Rotary Kiln Project for Zinc Oxide Recovery
Installation :
PROVIDED
Color :
Customized
Type :
ROTARY KILN
Description

The zinc-containing input materials are enriched in our rotary kiln using the so-called Waelz process to form Waelz oxide with a zinc content of at least 56 %. For this purpose, the input materials are introduced into the 40 m long rotary kiln together with other additives and handled at approx. 1,200°C.

Activated Carbon Rotary Kiln Lime Zinc Contenting Waste Material Kiln Furnace

Zhengzhou Hengyang Industry deploys the reliable rotary Kiln technology that successfully processes over 80% of the world’s recycled steel dust (EAF Dust). The rotary Kiln process is an established, energy-efficient and resilient technology used to treat zinc containing materials and residues.

Activated Carbon Rotary Kiln Lime Zinc Contenting Waste Material Kiln Furnace

Technical details:

Capacity: 50-150t/d

Calcination Temp: 400°C--1650°C

Diameter: 2000mm-4000mm

Length: 45000mm—70 000mm

Power: According to the kiln and its capacity.

Material: Q235, G20, 310S, 253MA, 309S, Q245, etc.

Activated Carbon Rotary Kiln Lime Zinc Contenting Waste Material Kiln Furnace

1 EAF Steel Dust Transport

2 Blending, conditioning and pelletizing of Kiln Feedstock

3 Main reaction Waelz Kiln

4 BSettling Chamber

5 Off Gas treatment

6 Clean air discharge

7 Waelz Zinc Oxide

End Uses of Zinc

Rotary Kiln Zinc Oxide is the main product of recycling EAF dust utilizing the Waelz Kiln technology. This product is sold to zinc smelters as an alternative to traditional zinc concentrates from mines. The zinc smelters produce pure zinc ingots or other high purity zinc products that are either sold to the steel industry for galvanization purposes or sold to other end-users for pigments, tires, chemicals or medicines.
