PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
Specifications
Place of Origin :
China
Brand Name :
QRZ
Packaging Details :
Regular packaging
Supply Ability :
100 units/day
Price :
$9.00 - $23.00/sets
MOQ :
1
Delivery Time :
5-8 weeks
Condition :
New
Weight (KG) :
40
Video outgoing-inspection :
Not Available
Machinery Test Report :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
Pressure vessel
Warranty :
1 Year
Applicable Industries :
Food & Beverage Factory, Other
Showroom Location :
None
Product name :
Submersible MBR Unit
Application :
Solid-Liquid Separation in water treatment
Material :
PDVF
Type :
hollow fiber membrane
Operating pressure :
-0.02-0.05Mpa
Operating temperature :
15-40℃
Port :
Qingdao, Shanghai, Tianjin
Description
PVDF Curtain Membrane for Submerged MBR Hollow Fiber Ultrafiltration Weight KG 40
Product Description
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
Specification
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
Basic parameters of hollow fiber curtain membrane modules
membrane modules model
QRZ-10
QRZ-15
QRZ-18
QRZ-20
effective membrane area
10㎡
15㎡
18㎡
20㎡
dimensions
1010*535*45 mm
1515*535*45 mm
1515*535*45 mm
2020*535*45 mm
membrane wire diameter (inner/outer)
1.1/2.2 mm
1.1/2.2 mm
1.1/2.2 mm
1.1/2.2 mm
filtration aperture
0.05um
0.05um
0.05um
0.05um
porosity
50-70%
50-70%
50-70%
50-70%
recommended
aeration rate
5m³/h*piece
5m³/h*piece
5m³/h*piece
5m³/h*piece
longitudinal strength
≥200N
≥200N
≥200N
≥200N
filtering mode
submerged sucking filtration
membrane modules model
QRZ-15
QRZ-20
QRZ-35
QRZ-40
membrane modules model
15㎡
20㎡
35㎡
40㎡
dimensions
1250*1000*30mm
1250*1500*30mm
1250*2000*30mm
1250*2000*30mm
membrane wire diameter (inner/outer)
1.1/2.2 mm
1.1/2.2 mm
1.1/2.2 mm
1.1/2.2 mm
filtration aperture
0.05um
0.05um
0.05um
0.05um
porosity
50-70%
50-70%
50-70%
50-70%
recommended
aeration rate
60-120m³/㎡*h(㎡=Projected area of membrane components)
longitudinal strength
≥200N
≥200N
≥200N
≥200N
filtering mode
submerged sucking filtration
Packing & Delivery
PVDF Curtain Membrane For Submerged MBR Hollow Fiber Ultrafiltration 40KG
Wooden box packaging
Company Profile
Beijing Qinrunze Environmental Protection Technology Co.,Ltd (QRZ), established in 2009, is a integrated solution provider in the field of water treatment, covering landfill leachate treatment, food waste treatment, industrial waste water treatment, sanitary waste treatment, mine waste water treatment. Business scope of QRZ encompasses the whole process of water treatment, ranging from engineering design, equipment manufacture, installation & commissioning, project contracting to entrusted operation. QRZ is capable of producing Membrane Bioreactor (MBR), Ultrafiltration (UF), Nanofiltration (NF), Reverse Osmosis (RO), Disc Tube Reverse Osmosis (DTRO), A/O Unit and the associated equipment, unit and accessories.
FAQ
1. who are we?
We are based in Beijing, China, start from 2009,sell to Domestic Market(80.00%),South Asia(8.00%),Southeast
Asia(4.00%),Africa(4.00%),South America(2.00%),Mid East(2.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Sewage treatment equipment,Integrated sewage treatment equipment,Dissolved air flotation machine sewage treatment
equipment,Filters for water treatment,Industrial water treatment equipment

4. why should you buy from us not from other suppliers?
1: Over 10 years' experience in water treatment field. 2: Cost-effective products tailored to client's requirement. 3:Professional
international business team. 4:Over 300 projects completed, skillful pre-sale and after-sale engineer team.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,Credit Card;
Language Spoken:English,Chinese
