Against Water Reverse Flow Non Slam Check Valve Protect Pump
Against Water Reverse Flow Non Slam Check Valve Protect Pump
Against Water Reverse Flow Non Slam Check Valve Protect Pump
Against Water Reverse Flow Non Slam Check Valve Protect Pump
Against Water Reverse Flow Non Slam Check Valve Protect Pump
Against Water Reverse Flow Non Slam Check Valve Protect Pump
Against Water Reverse Flow Non Slam Check Valve Protect Pump
Against Water Reverse Flow Non Slam Check Valve Protect Pump
Specifications
Brand Name :
AFC,OEM
Model Number :
NSCV
Certification :
WRAS, NSF61/372
Place of Origin :
China
MOQ :
1
Price :
Price negotiable
Payment Terms :
L/C, T/T
Supply Ability :
Based on order
Delivery Time :
45-60 days
Packaging Details :
Plywood cases
Product Name :
Anti Water Hammer Non Slam Check Valve FBE Coated Hydrolic design
Model Code :
NSCV
Material :
Ductile iron GJS500-7
Standard :
EN1074-3, EN12233
Fuction :
Anti Water Hammer
Coating :
EPOXY
Color :
Blue
Head loss :
Low
Description

Against Water Reverse Flow Non Slam Check Valve Protect Pump

Description:

Non Slam Check Valve is used as protection device against reverse flow when power failure in areas where noise pollution or water hammering is an important issue. It has quiet performance and low head loss.

Features:

NSCV is used against water reverse flow suddenly and protects pump and other devices from water hammer harmness.

Advance diffuser design maintains the streamline flow and reduces the water head loss to save pumping power.

Sphere disc head design makes flow resistance coefficient lower than flat type does.

Powder fusion epoxy coating NSF certificated.

Bronze bushing can reduce the stem wearing while working and last the service time.

Choosing the suitable NSCV into working,can return the investment around one year by pumping energy saving

Closing speed is very quick(max 0.2sec) and the stroke is only about 20% of valve bore diameter. Ensure non slamming and minimize the water hammer by hydrodynamic design with spring

Technical Data:

Size DN50-DN600
Working Temperature - 10C- 80C
Flange AISI B16.1 Or PN16
Flow Media Clean Water

Service Fields:
Generally used forprecleaned sewage water, clean water, Fire-fighting, Irrigation, Cooling and HVAC System.

Dimension:

DN50 - DN350

Against Water Reverse Flow Non Slam Check Valve Protect Pump

Against Water Reverse Flow Non Slam Check Valve Protect Pump

DN400 - DN600

Against Water Reverse Flow Non Slam Check Valve Protect Pump

Against Water Reverse Flow Non Slam Check Valve Protect Pump

Materials:

DN50-DN350

Against Water Reverse Flow Non Slam Check Valve Protect PumpAgainst Water Reverse Flow Non Slam Check Valve Protect Pump

Against Water Reverse Flow Non Slam Check Valve Protect PumpAgainst Water Reverse Flow Non Slam Check Valve Protect Pump

Against Water Reverse Flow Non Slam Check Valve Protect Pump
