Automatic Glass Bottle Juice Beer Vertical Filling Machine

Quick Detail

Desription

The series of equipment combines the rinsing, filling, sealing functions on the same machine. The design of the machine is scientific and reasonable .The appearance is beautiful and the function is complete. Its operation and maintenance is convenient. And its automation is high. The whole machine is controlled by PLC with touch-screen as the interface between human and machine .The amount of the drinks in the drink tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle .When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.

Technical Data:

Characteristics

1, The rinsing machine using high-strength stainless steel bottles of spring-loaded folders, to ensure a stable reversal of the glass bottles. The nozzle is a plum like structure can wash every corner of the sidewall and bottom to make the bottle clean.

2, Filling machine with spring-type mechanical lifting equipment to upgrade glass bottles, large bearing support floundering in the vat and use of guide-rod in the orientation of the structure, there are pre-cover features.

3, Using high precision mechanical filling valve, with cylinder liquid level and the back pressure controlled by a variable signal proportional. Fast, stable, accurate, to be vacuum one at a time.

4, Stainless steel plunger and mechanical stirring gland-type magnetic reasonable cap to ensure that the gland is healthy and reliable. Hopper and the cap taking- cover, capping transmitted by magnetic. The capping is reliable and automatic unloading, reducing the rate of broken bottles.

5, Before capping, using hot water bubble settings to displace bottlenecks air, ensuring the oxygen content of less than 0.15mg / L.

6, Filling machines includes broken bottle automatically stopping valve, broken bottle washing, and foam automatically exhausting device.

7, With perfect CIP cleaning function, and capable of rinsing filling pipes with acid, lye liquid or hot water.All the materials contacted with the valves, tanks, pipes are made of stainless steel N304 materials, inside and outside of the wall are mirror-polished, ensuring non- insanitary sites.

8, Manually dry oil lubrication system to make sure equipment maintenance more convenient.

9, The whole operation adopts advanced man-operational interface, PLC control, frequency conversion stepless speed regulation and other automatic control technology, with no bottle no open valves, no stamps; no caps no operation, and other security protection.

What service Reliable Machinery Co.,Ltd can offer you
• Your inquiry related to our product & price will be replied within 24hours
• Well-trained & experienced staff are to answer all your inquiries in English and Chinese
• Working time: 8:30am ~6:00pm, Monday to Friday(UTC+8).
• OEM & ODM projects are both available
• Your business relationship with us will be confidential to any third party.
• Good after-sale service offered, please get back to us if you got any questions


Warranty and Installation
1. Engineer will be sent to your side as soon as you get all your machines ready.
2. Installment USD60~150/day. Person as allowance
3. Training fee is free for customer’s workers within the installation period
4. We have one year warranty and come with at least one year recommended spare parts
