Round PET Bottle Water Filling Machine 3 In 1 Monoblock 1 Year For Spare Parts
Quick Detail:
Name: Water Beverage Filling Machine With Stainless Steel Standard
Material: Food stage stainless steel
Control: PLC & touch screen control
Capacity: 4000bph
Suitable Bottle: PET bottle
Bottle Volume: 0.3-2L
Dimension: By order
Function: washing filling capping 3 in 1
Technology: Advanced
After-sales service provided: Engineers available to service machinery overseas .
Description:
1. CGFA series washing,atmospheric pressure filling and capping three in one monoblock water beverage filling machine is one new equipment with many years experience in washing,filling and capping,adopting ideas from different customers and foreign advanced technology.
2. It can meet customers' demand that different size bottles can be operated in one filling machine,using hanging bottleneck manipulator makes change the bottle more convenient and quicker.
3. Enable the air convey the bottle automatically,rinsing,drying,filling,cap unscramble,under cap,screw cap automatically.
4. The full machines adopt the frequency conversion system,the speed can be adjusted without limit to make the operation of equipment more convenient and easier.mainly used for no-carbonated beverage (pure water,mineral water)washing,filling and capping
Round PET Bottle Water Filling Machine 3 In 1 Monoblock 1 Year For Spare Parts
Who will need our machines?
Specifications:
Model | CGF8-8-3 | CGF12-12-6 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 |
Rinsing Head No | 8 | 12 | 18 | 24 | 32 |
Filling Head No | 8 | 12 | 18 | 24 | 32 |
Capping Head No | 3 | 6 | 6 | 8 | 10 |
Rated Capacity (500ml) | 2000BPH | 4000BPH | 7000-8000BPH | 10000-12000BPH | 12000-15000BPH |
Overall Size | 1900*1420*2000mm | 2200*1600*2300mm | 2450*1900*2300mm | 2750*1180*2400mm | 4000*2300*2300mm |
Weight | 1.5T | 2.2T | 3.0T | 4.0T | 8.0T |
Power(KW) | 3.0kw | 3.5kw | 4.0kw | 4.8kw | 7.6kw |
Rated Voltage | 380V | 380V | 380V | 380V | 380V |
Competitive Advantage:
Round PET Bottle Water Filling Machine 3 In 1 Monoblock 1 Year For Spare Parts
General Information
Design Ability | All the machines designed by CAD |
Manufacturing Ability | Mechanical parts: high quality stainless steel, processed by CNC |
Reliability | Electrical parts from world famous suppliers |
Professional | Focus on beverage and pharmaceutical packing machines Exported to over 45 countries with good reputation 10 years Alibaba Golden supplier without complaint |
Good Service: | Service include complete production line design, manufacturing, on-site installation & aftersales maintenance. |
Export Experience | Exported to over 45 countries, with good reputation. |
Profession on Export: | Authorized import & export licence. |
Our Company
Zhangjiagang Reliable Machinery Co., Ltd is specialized in beverage production and packing equipment as well as water treatment machines. We are one of the companies engaged in manufacturing liquid filling and packing equipment in China.
Our products include: Liquid filling machines (water, fruit juice/tea, carbonated drink, oil, alcohol, plant protein drink, etc.), Barreled filling line (3-5 gallon) Water treatment machines, Labeling & packing machines, semi-automatic/full automatic bottle blowing machines, and injection molding machines.
What service Reliable Machinery Co.,Ltd can offer you ?
