Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
Specifications
Place of Origin :
Guangzhou, China
Brand Name :
YICHENG
Certification :
CE
Model Number :
DF15, DF20, DF25, DF40, DF50, DF65, DF80, DF100
MOQ :
one piece
Price :
negotiation
Packaging Details :
carton, film
Delivery Time :
within one week
Payment Terms :
T/T, western union, L/C
Supply Ability :
1000000pcs/month
Description

CE Brass Water Fountain Equipment 2 - Way Solenoid Valve IP68

Description:

Characteristic: 1.with diaphragm construction for fountain use matched with watertight coil

2. Opening speed at 10 times per second

Medium: Water

Temperature: NBR:-10℃ ～ 80℃

Pressure: 0.03 ～ 0.5Mpa

Prot Size: 1/2″,3/4″,1″,11/4″,11/2″, 2″,F21/2″,F3″,F4″

Orifice(mm): DN15,20,25,32,40,50,65,80,100

Voltage: DC: 36V, 24V

AC: 220/230V, 110/120V, 24V (50/60HZ)

Coils: F14B, 8VA(AC), 20W(DC), IP68,100%ED

Advantage:

1. Wear resistance

2. Good sealing performance

3. Light switch

4. Long service life

Features:

1) Investment Casting Body And Cap

2) Working Pressure 1/2”~2” 1000PSI, 2” ~ 3” 800PSI

3) Adjustable Steals And Seats

4) Pure Teflon Seals And Seats

5) Blow-Out Proof Stem

6) 100% Leakage Tested At 100 OSI Air Under Water

7) Hydrostatic Test Pressure:

8) 1/2” ~ 2” 1500 PSI, 2 1/2” ~ 3” 1200PSI

9) Locking Device (Option)

Material:

Body: Brass or Stainless Steel or Cast Iron

Seal: NBR, EPDM, PTFE or VITON

Armature: Stainless Steel 304

Stop: Stainless Steel 430F

Plunger: Stainless Steel 430F

Springs: Stainless Steel 304

Shading Rings: Stainless Steel 304

DF series, normally closed.With Coils F14B

Port Size Orifice Cv Min Pressure Max Pressure Seal Material Body Material Valve Body Coils
AC(28VA) DC(20W)
1/2″ 15 9.3 0.0MPa 0.5MPa 0.5MPa NBR Brass or Stainless Steel DF15XXX F14B
3/4″ 20 9.3 0.0MPa 0.5MPa 0.5MPa DF20XXX F14B
1″ 25 12 0.0MPa 0.5MPa 0.5MPa DF25XXX F14B
11/4″ 32 24 0.03MPa 0.5MPa 0.5MPa DF32XXX F14B
11/2″ 40 29 0.03MPa 0.5MPa 0.5MPa DF40XXX F14B
2″ 50 48 0.03MPa 0.5MPa 0.5MPa DF50XXX F14B
Port Size Orifice Cv Min Pressure Max Pressure Seal Material Body Material Valve Bdoy Coils
AC(28VA) DC(20W)
F21/2″ 65 68 0.03MPa 0.5MPa 0.5MPa NBR Cast iron DF65FXX F14B
F3″ 80 100 0.03MPa 0.5MPa 0.5MPa DF80FXX F14B
F4″ 100 175 0.03MPa 0.5MPa 0.5MPa DF100FXX F14B

Water Fountain Valve 2 Way High Pressure Solenoid Valve with NBR EPDM PTFE Seal
