Water Treatment Above Ground Pool Sand Filter For Home Water Filtration
Water Treatment Above Ground Pool Sand Filter For Home Water Filtration
Water Treatment Above Ground Pool Sand Filter For Home Water Filtration
Water Treatment Above Ground Pool Sand Filter For Home Water Filtration
Specifications
Place of Origin :
China
Brand Name :
YICHENG
Certification :
CE
Model Number :
DDG series
MOQ :
one piece
Price :
negotiation
Packaging Details :
Carton
Delivery Time :
7-10 days
Payment Terms :
Ex-worked
Supply Ability :
100PCS/week
Description

Water Treatment Above Ground Pool Sand Filter For Home Water Filtration

Description:

High quality and high performance are aesthetically designed for water treatment.

High density fiberglass sand filters are constructed by the latest engineering technology. The improvement of flow ability provides an ultra-pure water filtration. The fiberglass winding design allows the filter to have extra strength and resistance to chemical and corrosives. They're the most recommendable equipment for the application of water treatment.

FEATURES:

Easy to Clean

Suitable for use with Automatic Pool Cleaners

High quality 6 position multi-port valve

Self-sealing barrel unions

Transparent lid for inspection of filtered water

Ring lock design for quick opening and closing, Thereby eliminating

The use of traditional screws

* Use only #20 white silica sand, size range 0.4-0.55mm.

Maximum working pressure: 2.5kg/cm² ; Maximum temperature: 50° C(122° F)

Model Pipe size Filter Area Design flow Sand weight Height Standard volume Standard weight
(inches) m2 m3/h 0.4-0.8mm (kg) mm m3 kg
DDG13400 1.5 0.13 4.6 112 1300 0.35 24
DDG13450 1.5 0.17 5.6 143 1300 0.42 27
DDG13500 1.5 0.20 7.0 172 1300 0.50 30
DDG13600 1.5 0.28 9.8 230 1300 0.68 33
DDG13700 1.5 0.37 13.3 325 1300 0.89 42
DDG15400 1.5 0.13 3.9 141 1500 0.38 28
DDG15450 1.5 0.15 4.8 185 1500 0.48 32
DDG15500 1.5 0.20 6.0 225 1500 0.56 35
DDG15600 1.5 0.28 8.4 307 1500 0.78 39
DDG15700 1.5 0.37 13.3 430 1500 1.03 47

Working pressure: 2.5kg/cm2

Testing pressure: 4kg/cm3

Maximum temperature: 43 degree

Size of sand: 0.5-0.8mm

Water Treatment Above Ground Pool Sand Filter For Home Water Filtration

Water Treatment Above Ground Pool Sand Filter For Home Water Filtration
