Specifications
Brand Name :
YICHENG
Model Number :
DG series
Certification :
CE
Place of Origin :
China
MOQ :
one piece
Price :
negotiation
Payment Terms :
Ex-worked
Supply Ability :
100PCS/week
Delivery Time :
7-10 days
Packaging Details :
Carton
Material :
plastic
valve :
Top mount multi port valve
Body color :
deep greay
Size :
350mm - 700mm
Working pressure :
2.5kgs
Size of sand :
0.5-0.8mm
Description

Top Mounted Plastic Swimming Pool Sand Filters For Ponds Filtration Deep Grey Color

Description:

Product features:
* using food grade high density polyethylene (HDPE) material, corrosion resistance, safer, more environmentally friendly
* the body adopts the integration of thermoforming, makes the body is stronger, more stable quality, can ensure that is not affected by the influence of the bad weather, can make the filter and stable operation for many years
* 6 multi-way valve, combines many functions in one, the only need to handle gently rotating can easily implement, operation more simple
* mixed color machine and line clip round base, allowed to rotate 360 degrees, ease of installation
* size optimization design, save the space machine installation and operation
This product is suitable for: small pool, home swimming pool, SPA pool, aquarium, waterscape fountain, etc

FEATURES:

Easy to Clean

Suitable for use with Automatic Pool Cleaners

High quality 6 position multi-port valve

Self-sealing barrel unions

Transparent lid for inspection of filtered water

Ring lock design for quick opening and closing, Thereby eliminating

The use of traditional screws

* Use only #20 white silica sand, size range 0.4-0.55mm.

Maximum working pressure: 2.5kg/cm² ; Maximum temperature: 50° C(122° F)

Model Pipe size Filter Area Design flow Sand weight Tank volume Tank weight Valve volume Valve weight
(inches) m2 m3/h 0.5-0.8mm (kg) m3 kg m3 kg
DG350 1.5 0.10 4.5 25 0.06 4.0 0.02 3
DG400 1.5 0.13 6.5 34 0.09 5.0 0.02 3
DG450 1.5 0.16 8.0 50 0.15 6.5 0.02 3
DG500 1.5 0.23 11.5 80 0.20 9.2 0.02 3
DG650 1.5 0.32 16.0 160 0.32 12.1 0.02 3
DG700 1.5 0.40 20.0 220 0.42 17.0 0.02 3

Working pressure: 2.5kg/cm2

Testing pressure: 4kg/cm3

Maximum temperature: 43 degree

Size of sand: 0.5-0.8mm

Top Mounted Plastic Swimming Pool Sand Filters For Ponds Filtration Deep Grey Color

Top Mounted Plastic Swimming Pool Sand Filters For Ponds Filtration Deep Grey Color

Top Mounted Plastic Swimming Pool Sand Filters For Ponds Filtration Deep Grey Color
