Specifications
Brand Name :
YICHENG
Model Number :
CBtT series
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
negotiation
Payment Terms :
Ex-worked
Supply Ability :
1, 000,000pcs/week
Delivery Time :
5-10 days
Packaging Details :
carton
Material :
Fully Brass material
Thread :
female
Size :
DN15 - DN80
Outlet :
one piece
Pattern :
Straight Column Foam
Adjustalbe :
yes
Description

Adjustable Cascade Water Fountain Nozzles Fountain Ice Tower Head Brass Material

Description:

Cascade fountain nozzle dependent upon the water level.which is in contrast to foam spray and foam spring nozzle.

Because of the injection effect,the surrounding water and air are sucked in, intensively mixed and thrown high into the air by the injector jet.

This has an economical effect,since with a relatively low pumping power one can achieve a voluminous tapered fountain jet.

Return valves must be provided in installations with different water levels,since otherwise when switching off,the water level sinks to the injection height,

which would lead,when switching on again,to the jet being significantly higher until the normal water level was reached.

The Cascade Nozzle is the single most popular effect used in commercial and architectural fountains through modern times. They can be used in a wide variety of ways to achieve spectacular effects. Whatever your plan or inspiration calls for, the Cascade can probably fill the bill. A water entraining venturi type nozzle, the Cascade augments its spout effect by adding water volume from the pool. In doing so, a very heavy, powerful effect is achieved with little aeration.

Cascade nozzles are used widely in architectural fountains, due to their high visibility and good wind resistance, exhibiting a very "hard" visual and audible impact suitable for large pools and outdoor applications where noise masking water effects are desired. The Cascade is water level dependent, and requires a controlled water level. In addition, opaque water walls are easily achieved when several nozzles are placed in close proximity.

Specifications

Brass Material:

Model Performance Water Inlet Water Outlet Size Weight
pressure (Kpa) capacity (m3/h) height (m) coverage (m) diameter (inch) connection type diameter (mm) number (pcs) height (mm) max dia. (mm) (kg)
CBtT80 80-450 55-65 1-12 1-1.5 3" external thr. Ф91 * Ф24 * 1 283 123 1.66
CBtT65 80-450 55-65 1-12 1-1.5 2 1/2" internal thr. Ф91 * Ф24 * 1 283 123 1.66
CBtT50 80-400 35-45 1-10 0.8-1.0 2" Ф73 * Ф19 * 1 200 94 1.1
CBtT40 50-300 20-35 1-8 0.5-0.6 1 1/2" Ф66 * Ф16 * 1 180 86 0.75
CBtT25 40-200 8-12 1-5 0.2-0.3 1" Ф46 * Ф12 * 1 123 60 0.35
CBtT20 40-100 3-5 1-3 0.2 3/4" external thr. Ф30 * Ф10 * 1 89 44 0.13
CBtT15 40-100 2-4 1-3 0.15 1/2" internal thr. Ф25 * Ф8 * 1 71 33 0.07
