Specifications
Brand Name :
YICHENG
Model Number :
M-660P
Certification :
CE
Place of Origin :
Guangzhou, China
MOQ :
one piece
Price :
negotiation
Payment Terms :
T/T, western union, L/C
Supply Ability :
1000000pcs/month
Delivery Time :
within one week
Packaging Details :
carton
Output :
125psi
Duty Cycle :
Continuous
Package including :
full set of tubes, inlet valve, mounting tools and
Max pressure :
4 bar
Flow :
13 L/h
Voltage :
220V
Description

PH / Chlorine Swimming Pool Control System Dosing Pump For Chemical Feeding

The M-600P series dosing pump

1.high efficiency performance dosing pump
2.smart and automatic, auto-control dosing chemical volume
3.accurately distributing

4.easy maintainance and installation

5.other dosing pump requests , be freely contacting us!

Product Advantage

The M-660P series dosing pump has double-ball ceramic check valves, viton O'ring, PVDF(Kynar) valve, easy access, easy servcing, 27:1 adjustment turn down ratio, the outer pressure capability can be 125 PSI, its ball bearing supported motor drive shaft, one set including suction tube, foot valve & strainer,suction bube weight , suction tubing.

Discharge tubing and injection fitting with internal back-flow check valve and Mounting hardware.

Application:

*Swimming Pool
*water parks
*Ocean pavilions
*Ponds, etc.

Model Max. GPD Max. GPH Max.LPH Strokes Per Minute Max.PSI
M-660P 110 4.6 17.4 60 60

Specifications

Maximum Working Pressure 125 Psi/8.6 bar*
Maximum Fluid Temperature 130 F / 54℃
Output Accuracy +/- 10% of maximum(water@70°F, 0 psig, and 5'suction lift
Ambient Temperature Range 14 to 110°F / -10 to 43℃
Enclosure Zinc Metal
Duty Cycle Continuous
Maximum Viscosity 1,000 Centipoise
Maximum Suction Lift up to 10ft. Water
Power Requirements 115V 60Hz 45 Watts
220V 60Hz 45 Watts
230V 60Hz 45 Watts
24V 60Hz 45 Watts
Dimensions 6-1/2 high x 6-1/2 wide x 5-3/4 deep
Weight 81b.
