Specifications
Brand Name :
YICHENG
Model Number :
QY series
Certification :
CE
Place of Origin :
Guangzhou, China
MOQ :
one piece
Price :
negotiation
Payment Terms :
T/T, western union, L/C, Ex-worked
Supply Ability :
1000000pcs/month
Delivery Time :
within one week
Packaging Details :
carton
Material :
Cast Iron
Speed :
2860 rpm
Type :
Oil filled
Phase :
3 phase
Depth into water :
0.5m - 50m
Water quality :
solid impurity is less than 0.1%
Description

Oil-Filled Cast Iron Submersible Fountain Pumps For Fountain Projects


Description:

QY series oil-filled type is pump and three-phase asynchronous electric submersible pump units into electric power irrigation and drainage machinery. With small volume, light weight, mobile convenience, easy installation and don't need to water before driving, etc. Widely used in agricultural irrigation, industrial water supply and drainage, municipal construction and fountain, engineering and other industries.
Working conditions:
Pumps should be fully into the water, diving depth of not less than 0.5 m, is not greater than 5 m.
For no corrosive water as the working medium, liquid or chemical properties of similar Yu Qingshui, the volume of water containing solid impurity is less than 0.1%, the particle size is not more than 0.2 mm, pH value of 6.5-8.5, the water temperature is not higher than 40 degree.
Three-phase power supply, 380 V, 50 Hz, the power supply voltage should be within 342-420 - V.

ModelFlow HeadPowerOutputRotate Max radialWeightFlange Size
Rate sizeSpeedsize x height outer sizeinner sizecertre distanceqty of bolt hole & size
(m3/h)(m)(KW)(mm)(rpm)(mm)(kg)(mm)(mm)(mm) (pcs) (mm)
QY8.4-40-2.28.4402.2282860261 x 5624312035954 - Φ9
QY15-26-2.215262.2402860261 x 6035212040954 - Φ9
QY25-17-2.225172.2502860260 x 5954512050954 - Φ9
QY65-7-2.26572.2892860237 x 628451801001656 - Φ9
QY10-36-2.210362.2402860285 x 5906012040954 - Φ9
QY100-4.5-2.21004.52.21352860242 x 642451841251656 - Φ9
QY160-3-2.216032.21402860285 x 630501881401704 - Φ9
QY10-50-310503402860242 x 5905012040954 - Φ9
QY160-4-3160431402860292 x 685551951401756 - Φ9
QY25-26-325263502860285 x 61247/50852-M8
QY15-40-315403402860242 x 5905012040954 - Φ9
QY25-24-325243502860242 x 5904812050954 - Φ9
QY40-16-340163662860242 x 58850180801656 - Φ9
QY65-10-365103892860242 x 643461841001656 - Φ9
