380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
Specifications
Brand Name :
YICHENG
Model Number :
EPU-00, EPU-60, EPU-120
Certification :
CE
Place of Origin :
Guangzhou
MOQ :
one set
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000000m2/month
Delivery Time :
one week
Packaging Details :
plastic bag
Speed :
1-9 grade
Voltage :
380V
Material :
Fibreglass
Style :
Inground Pool
Cover :
2 types
Warranty :
3 years
Description

380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW

Description:
Owners of those small/medium sized swimming pools usually have trouble in enjoying swimming as they need to trun constantly when the swimming range is limited. As an innovative product for improving swimming experience. Our ENDLESS Swimming Pool Units perfectly solves this problem and brings you a real vila's pool for swimming.

Our Endless Swimming Pool Units come with an adjustable and powerful laminar flow ;propeller and a control system, which enables static water to flow directionally. When the swimmer swims aginst the direction flows, he will have the same feeling as swimming in a flowing river without the limitation caused by the pool's dimension and enjoy the benefit of fitness as well as the fun of swimming freely.

A whole set of circulation and filtration, disinfecting system is included all in these units, which saves you from complicated manual operation and expensive professional management. It is also excellent in saving the cost for the pool's operation and maintenance.

Main Features:
* Use the patented laminar flow propeller to impulse water to produce a circulation flow

* Powerful water flow

* Smooth water surface

* Make small/medium size pool a real swimming pool, instead of a landscape

* Can be applied into projects like newly-bulit small/medium size swimming pools and reconstruction of old pools

* System equipment can be custom-bulit according to different needs

* Adjustable flow rate according to different swimmers, feel like swimming in a real river

* Total 9 flow rates for optional on the speed controller

Speed 1 2 3 4 5 6 7 8 9
Flow rate (m/s) 0.9 1.2 1.5 1.7 1.9 2.2 2.5 2.8 3.1

Technical Data:

Model EPU-00 EPU-60 EPU-120
Voltage 380V 380V 380V
Current 6A 11.3A 13.5A
Total Power 2.2KW 4.3KW 5KW
Pump Power / 1x1HP 2x1HP
Design flow rate / 8m3/h 16m3/h
Filtration Area / 0.16m2 0.32m2
Pool Volume / ≤64m3 ≤128m3
N.W.(kg) 203 358 388
G.W.(kg) 235 410 440
Size(mm) 970x970x1235 1810x885x1235 1810x885x1235

Model Main Parts Remarks
EPU-00 Submerged pump, frequency changer, laminar flow propeller, controller Excluding filtration system
EPU-60 Pump, filters, submerged pump, frequency changer, UV, laminar flow propeller, controller, chemical feeder Including filtration system
EPU-120 Pump, filters, submerged pump, frequency changer, UV, laminar flow propeller, controller, chemical feeder Including filtration system

Installation Diagram:

380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW

380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW

380V Swimming Pool Control System , Fibreglass Swimming Pool Equipment 2.2KW
