Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
Specifications
Brand Name :
autumn solar
Model Number :
QSPB65-13--4
Certification :
ce
Place of Origin :
made in China
MOQ :
one PC sample order acceptable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 pcs / month
Delivery Time :
10-15 days
Packaging Details :
wood case
name :
water fountain pump
model :
QSP65-13-4
power :
4KW/380V/50HZ
flow rate :
65 m3/h
head :
13m
material :
stainless steel
pump type :
submersible pump, centrifugal pump
drive mode :
electricity
impeller structure :
closed impeller
impeller quantity :
one stage
Description

China 380V landscape submersible stainless steel fountainwater pump

introduction of stainless steel water fountain pump :

QSPB water fountain pump is our newly developed product.

The pump motor is made of high quality material DR470 cold-rolled steel, evening to increase the number of turns of windings and diving line wire diameter, cable in three phase four wire type JHS fountain, special cables, impeller increases the loose prevention device;

Motor chamber adopts imported antirust enamel, through the above structure improvements make submersible pump inertia small, thus the response speed, with high performance special shaft bearing, to improve the insulation level, so as to meet the needs of the special music fountain, frequent starting.

Caution: Do not operate for long time when there is no water in the pump

TECHINCAL PARAMTER:

No. model Flow rate Head Power Outlet diameter Speed Product size Flange
(m3/h) (m) (KW) (mm) (rpm) (diaXH) mm Outer dia.(mm) Inner dia.(mm) Hole centre distance Bolt size and qty
1 QSPB15-14-1.1 15 14 1.1 50 2860 148X470 140 50 110 4- Φ11
2 QSPB25-9-1.1 25 9 1.1 65 2860 140X465 156 65 135 4- Φ11
3 QSPB40-6-1.1 40 6 1.1 70 2860 154X471 156 70 135 4- Φ11
4 QSPB65-7-2.2 65 7 2.2 100 2860 158X550 170 100 150 4- Φ11
5 QSPB25-17-2.2 25 17 2.2 65 2860 158X540 156 65 135 4- Φ11
6 QSPB40-12-2.2 40 12 2.2 80 2860 180X555 180 80 160 4- Φ11
7 QSPB65-10-3 65 10 3 100 2860 158X570 170 100 150 4- Φ11
8 QSPB40-16-3 40 16 3 80 2860 158X575 180 80 160 4- Φ11
9 QSPB100-9-4 100 9 4 90 2860 180X592 180 90 160 4- Φ11
10 QSPB65-13-4 65 13 4 90 2860 180X592 180 90 160 4- Φ11
11 QSPB40-21-4 40 21 4 80 2860 180X588 180 80 160 4- Φ11
12 QSPB25-32-4 25 32 4 65 2860 203X578 165 65 145 4- Φ11
13 QSP100-12-5.5 100 12 5.5 90 2860 180X642 180 90 160 4- Φ11
14 QSP65-18-5.5 65 18 5.5 90 2860 203X589 180 90 160 4- Φ11
15 QSP40-28-5.5 40 28 5.5 80 2860 203X585 180 80 160 4- Φ11
16 QSP160-8-5.5 160 8 5.5 120 2860 203X597 210 120 190 4- Φ11
17 QSP32-30-5.5 32 30 5.5 70 2860 180X736 165 70 134 4- Φ11
18 QSP30-36-5.5 30 36 5.5 70 2860 180X736 165 70 134 4- Φ11
19 QSP50-24-5.5 50 24 5.5 80 2860 203X585 180 80 160 4- Φ11
20 QSP20-50-5.5 20 50 5.5 70 2860 180X850 165 70 134 4- Φ11
21 QSP100-15-7.5 100 15 7.5 90 2860 180X672 180 90 160 4- Φ11
22 QSP65-25-7.5 65 25 7.5 80 2860 203X642 180 80 160 4- Φ11
23 QSP160-11-7.5 160 11 7.5 120 2860 203X654 210 120 190 4- Φ11
24 QSP80-20-7.5 80 20 7.5 90 2860 203X657 180 90 160 4- Φ11
25 QSP40-40-7.5 40 40 7.5 80 2860 180X798 180 80 160 4- Φ11
26 QSP30-50-7.5 30 50 7.5 70 2860 180X880 165 70 134 4- Φ11
27 QSP32-45-7.5 32 45 7.5 70 2860 180X880 165 70 134 4- Φ11
28 QSP50-36-7.5 50 36 7.5 80 2860 180X798 180 80 160 4- Φ11

Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head

APPLICATION:

Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head

Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head

Landscape Stainless Steel Water Pump , City Square Centrifugal Pond Pump 13m Head
