100W 36-48V 2.3A UFO Hbg Grow Light Power Supply waterproof LED Driver
100W 36-48V 2.3A UFO Hbg Grow Light Power Supply waterproof LED Driver
100W 36-48V 2.3A UFO Hbg Grow Light Power Supply waterproof LED Driver
100W 36-48V 2.3A UFO Hbg Grow Light Power Supply waterproof LED Driver
100W 36-48V 2.3A UFO Hbg Grow Light Power Supply waterproof LED Driver
100W 36-48V 2.3A UFO Hbg Grow Light Power Supply waterproof LED Driver
Specifications
Brand Name :
turefull
Model Number :
ZF-HBG-100-36
Certification :
SAA,TUV
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
2000pcs per month
Delivery Time :
5-8 work days
Packaging Details :
Carton Box
Output power :
100W
Protections :
Shortcuit Overtemp Overload Overtemp, Short Circuit Overtemp Overload Overvolt, Over-voltage;over-load
Material :
Aluminum
Ip rate :
IP67
Power factor :
0.98
Output voltage :
36V /42V/48V/54V
Size :
130*70
Warranty :
3 years
Description

100W High Quality UFO Hbg Grow Light Power Supply LED Driver

Features

1.UFO LED driver in constant current type

2.protection design:Short-circuit protection,over-voltage protection,over-current protection,over-temperature protection.

3.high PFC>0.98,high efficiency>88%

4.Function:Current adjustable,1-10V dimmable led driver

5.IP grade:IP67 waterproof

6.Application:UFO led light,street lighting,tunnel lighting

Technical parameter

Part Number HBG-100-36 HBG-100-48 HBG-100-60 HBG-100-72
OUTPUT DC VOLTAGE 27~36Vdc 36~48Vdc 48~60Vdc 60~72Vdc
CONSTANT CURRENT REGION Note.4 2.7A 2.1A 1.6A 1.38A
RATED POWER 100W
RIPPLE & NOISE(max.) Note.2 2000mA Max 1500mA Max 1200mA Max 1000mA Max
CURRENT TOLERANCE Note.3 ±3.0%
LINE REGULATION ±3.0%
LOAD REGULATION ±3.0%
SETUP, RISE TIME(Typ.) Note.7 300ms 230VAC at full load
INPUT VOLTAGE RANGE Note.5 90 ~277VAC
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR(Typ.) >0.98 at 100Vac&full load; >0.95 at 230Vac&full load
EFFICIENCY(Typ.) 88% 89% 90% 91%
AC CURRENT(Typ.) 0.58A/115VAC 0.29A/230VAC
INRUSH CURRENT(Typ.) COLD START 40A ( Twidth=270us measured at 50% Ipeak ) at 230VAC
LEAKAGE CURRENT <0.75mA/265VAC
OTHERS MTBF 200khrs min. MIL-HDBK-217F (25℃)
DIMENSIION 110*64MM(L*W*H)
PACKING 380±10g

Dimensions

100W 36-48V 2.3A UFO Hbg Grow Light Power Supply waterproof LED Driver
