120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W
120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W
120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W
120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W
120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W
120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W
Specifications
Brand Name :
CLASSIC
Model Number :
JD-1036A
Certification :
CE.EMC.LVD
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, L/C, D/P
Supply Ability :
10005pcs/Month
Delivery Time :
15-30days
Packaging Details :
5 layer cartons
Material :
ADC12 aluminum
Color :
grey/dark grey/black
Ip rating :
IP66
Working temperature(℃) :
-40 - 49
Cri (ra>) :
75
Input voltage(v) :
100-241VAC
Application :
Roadway,outdoor,garden
Lamp luminous efficiency(lm/w) :
105
Warranty(year) :
5
Working lifetime(hour) :
50010
Description

30W Outdoor Garden Lamp LED Post Top Pole Lights Fixtures Yard light

All about simplicity, functionality and visual comfort, so it is particularly suited to residential and green area applications. It comes with three optics, a range of column and bracket options.

This simple yet effective street luminaire offers a range of street optics using reflector technology. offers a range of dimming and colour temperature options to fit most applications.

Post Top LED Luminaire features a traditional decorative style to make it an excellent choice for new construction or retrofit applications.Provide style and elegance to downtown areas, commercial developments, parks and residential communities.Pressing the screws, that guarantee the tightness of the product, the cover on which the LED modules are attached is released. Installation on Ø 76 mm poles with or with an arm.
0-10V dimming optional

Specifications:

Power:30W

Voltage: AC100-277V

CCT:5700K

Luminous flux:3000lm

Waterproof rating: IP66

Working temperature: -29℉-113℉

Material: Die-casting aluminum + PC

Lifespan: 50000 hours

Chip brand:

Features :

* Suitable to diameter 76mm pole.
* High brightness LED chips 100lm/w
* Dusk to dawn Photocell function available
* 0-10V Dimmable/DALI/PMMA available
* IP66 waterproof rating
* Different type lens for choice
* Working environment in -40℃to 51℃
* CE/ROHS/LM79/LM80 for quality assurance and safety operation
* IES files are available
* 5 years warranty


Application:

Square Lighting,Car Park, Highway, Stadium

Petrol Station, lighting parks

parking lots, campuses, walkways, side roads,etc


Specification :

Model JD-1036A 30W JD-1036B 60W JD-1036C 60W
Wattage 30W 60W 60W
Beam Angle 120 Degree
Luminous Flux 3000lm 6000lm 6000lm
Color Temperature 2700K~6500K
Input Voltage AC100-277V, 50-60Hz
Life Hours 50,000
LED Chip 3535/ 3030 smd
CRI Ra>80
PF >0.92
Surge Voltage 10V/20KV
IP Rating IP66
Dimension L554*W377*H305mm
Product dimension:

120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W

BOM pictures :

120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W

Product distribution curve :


120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W
120 Degree AC 100V - 277V Outdoor LED Yard Lights 30W

​
