High brightness: 130-150LM/W.
Housing: Die-cast Aluminum.
Optical: Anodized aluminum reflector and PC diffuser.
Finishing: Surface anti-aging electrostatic spray processing, super resistance to corrosion
Dust and snow proof: Adopt smooth die-cast aluminum housing,successfully prevent the dust and snow from acumulating on the housing,thus better heat dissipation and longer life span.
Certifications: TUV,CB,CE,LM79,LM80,IP66

An optional house-side shield, and a post-top mounting bracket. Colour temperatures offered are 4000K (standard), and 3000K or 5000K (optional).

LED fitting for the lighting of roads and cycle-pedestrian paths. Of simple and functional design, it is available in standard version fitted with a virtual midnight self-learning system with possibility of selection among pre-defined programs of power reduction,

Pressing the screws, that guarantee the tightness of the product, the cover on which the LED modules are attached is released. Installation on Ø 76 mm poles with or without an arm.

• High brightness LEDs, CRI RA>70, 90 to 110lm/w & 2700-6500K selectable
• Power factor >0.95, total harmonic distortion <10%
• AC 100 to 277V wide application potted dirver with multi protections of short circuit, open circuit, zero load, over load, electron magnetic inteference
• Dual stage built-in surge protector 6KV and 10KV
• Aesthetical architecturelly design and make up of corrosion free high pressure die cast aluminum with well design of thermal managment system
• IP66 ingress protection to both optical and control gear compartment
• Tool free mounting with level gradienter, NEMA interface reserved
• Long maintenace free life, 50,000 hours for whole luminare

Specification :

Product Details :

Product dimension:

Product distribution curve :
