New Design Industrial Screw Tooth Type Black Shell 3+9 Pin Female Plug M19 Connector

Model: SW19-12K-LT (3+9 pin female plug)

☑Quick, simple self locking system
☑Connect reliably
☑Small size of product

☑Multi-style inner core design to meet the needs of various industries
☑Protection level: used in outdoor scenes, protection level up to IP67
☑Multiple cores -2,3,4,5,6,9,3+9 pin support multiple application scenarios
☑High-power industrial waterproof connector - waterproof, moisture-proof and dust proof
☑The connector is plated with gold/silver beryllium copper, which is oxidation and corrosion resistant to ensure fast signal
transmission and electrical conductivity

Products Description
SW19 Screw tooth series-3+9 Pin connector
M19 series is an industrial connector, which includes male plug, female plug and male socket.
The material selection of the inner core uses gold-plated pin, which is conducive to the stable passage of the current. A variety of cores can be selected, making its application field more extensive.
The cable skin is molded by a plastic wrap mold. All materials comply with environmental RoHS standards, and passed CE,UL,FCC and other multinational certification. Male coordinate with waterproof apron, the waterproof grade of the connector up to IP67.
There are two locking methods:
1. Push-pull self-locking connection
2. Plastic screw connection, both locking design is very reliable.
Self Locking M19 Connector Waterproof IP67 Electrical Female Connector
Self Locking M19 Connector Waterproof IP67 Electrical Female Connector
Self Locking M19 Connector Waterproof IP67 Electrical Female Connector
1. Electrical parameters
Contacts NO.
3+9 pin
Rated current
5A
Rated voltage
60V AC
Withstand voltage
125V
Insulation resistance
≥100mΩ
Contact resistance
≤10mΩ
2. Mechanical parameters
Service life
＞1000 times
Power line
Φ4.5mm-Φ11mm
Cable size
0.3mm²-2.5mm²(22AWG-12AWG)
Type of terminals
Screw terminal and soldering terminal available
3. Material and environmental parameters
Shell&insulated parts
High performance engineering plastics
Contacts
Copper alloy
Contact diameter
Φ1.0mm
Protection degree
IP67
Flame-retardant grade
UL94-V0
Temperature range
-40℃~105℃
4.Size reference (unit /mm)
